TR-069/TR-104
Parameter
MaxAddress
MinAddress
SubnetMask
14.4.2.1.3 Configuring VoIP via TR-104

Table 14-9: InternetGatewayDevice.Services.VoiceService.i.Capabilities

TR-069/TR-104
Parameter
ButtonMap
DSCPCoupled
EthernetTagging
Coupled
FaxPassThrough
FaxT38
MaxLineCount
User's Manual
Configuration File
Parameter
lan_host_config_managem
ent_get/set
rg_conf dhcps/end_ip
lan_host_config_managem
ent_get/set
rg_conf dhcps/start_ip
lan_host_config_managem
ent_get/set
rg_conf dhcps/ netmask
Configuration File
Parameter
-
-
-
-
-
voip/num_of_fxs_lines
218
MP-20x Multimedia Home Gateway
Description
Specifies the last address in the pool to be
assigned by the DHCP server on the LAN
interface.
Specifies the first address in the pool to be
assigned by the DHCP server on the LAN
interface.
Specifies the client's network subnet mask.
Description
Support for a configurable button map. A true
value indicates support for a configurable
button map via the
VoiceService.{i}.VoiceProfile.{i}.ButtonMap
object.
A true value indicates that the CPE is
constrained such that transmitted call control
packets use the same DSCP marking as
transmitted RTP packets.
If the value is true, the CPE must not support
the DSCPMark parameter for call control.
A true value indicates that the CPE is
constrained such that transmitted call control
packets use the same Ethernet tagging
(VLAN ID Ethernet Priority) as transmitted
RTP packets.
If the value is true, the CPE must not support
the VLANIDMark or EthernetPriorityMark
parameters within a call control object (e.g.,
SIP, MGCP, or H323).
Support for fax pass-through. A true value
indicates support for the parameter
VoiceService.{i}.VoiceProfile.{i}.FaxPassThro
ugh. (True if
voip/audio/fax/fax_transport_mode equals
Bypass)
Support for T.38 fax. A true value indicates
support for the object
VoiceService.{i}.VoiceProfile.{i}.FaxT38.
Maximum number of lines supported across
all profiles.
Document #: LTRT-50614
