VPLS Feature Guide for EX9200 Switches

LDP BGP Interworking Platform Support

Configuring FEC 128 VPLS Mesh Groups for LDP BGP Interworking

16
Configuring Switching Between Pseudowires Using VPLS Mesh Groups on page 17
Configuring Integrated Routing and Bridging Support for LDP BGP Interworking with
VPLS on page 18
Configuring Inter-AS VPLS with MAC Processing at the ASBR on page 18
LDP BGP interworking is supported on the following Juniper Networks routers and routing
platforms:
M7i
M10i
M40e
M120
M320
MX Series routers
T Series routers
TX Matrix routers
EX Series switches
To configure FEC 128 LDP BGP interworking for VPLS, include the
in the VPLS routing instance configuration of the PE border router:
mesh-group mesh-group-name {
local-switching;
mac-flush [ explicit-mac-flush-message-options ];
neighbor address;
peer-as all;
vpls-id number;
}
You can include this statement at the following hierarchy levels:
[edit routing-instances routing-instance-name protocols vpls]
[edit logical-systems logical-system-name routing-instances routing-instance-name
protocols vpls]
Using the statement, configure each PE router that is a part of the mesh group.
neighbor
You must separate the LDP-signaled routers and the BGP-signaled routers into their own
respective mesh groups. The LDP-signaled routers can be divided into multiple mesh
groups. The BGP-signaled routers must be configured within a single mesh group for
each routing instance.
statement
mesh-group
