family multiservice

Syntax
Hierarchy Level
Release Information
Description
Options
Copyright © 2016, Juniper Networks, Inc.

family multiservice {

destination-mac;
label-1;
label-2;
payload {
ip {
layer-3 {
(source-ip-only | destination-ip-only);
}
layer-3-only;
layer-4;
}
}
source-mac;
symmetric-hash {
complement;
}
}
[edit forwarding-options hash-key]
Statement introduced in Junos OS Release 8.0.
ip , label-1 , label-2 , layer-3-only
, .
layer-3 layer- source-ip-only
Release 9.5.
and
symmetric-hash complement
Configure load balancing based on Layer 2 media access control information. On MX
Series routers, configure VPLS load balancing. On M120 and M320 routers only, configure
VPLS load balancing based on MPLS labels and IP information. For IPv4 traffic, only the
IP source and destination addresses are included in the hash key. For MPLS and IPv4
traffic, one or two MPLS labels and IPv4 source and destination addresses are included.
For MPLS Ethernet pseudowires, only one or two MPLS labels are included in the hash
key.
You can configure one or more options to load-balance using the packet information
that you specify.
—Include the destination-address MAC information in the hash key for
destination-mac
Layer 2 load balancing.
label-1 (M120 and M320 routers only)—Include the first MPLS label in the hash key. Used
for including a one-label packet for per-flow load balancing of IPv4 VPLS traffic
based on IP information and MPLS labels.
(M120 and M320 routers only)—Include the second MPLS label in the hash key.
label-2
If both label-1 and label-2
the second label are hashed.
, and payload options introduced in Junos OS Release 9.4.
, and options introduced in Junos OS
destination-ip-only
options introduced in Junos OS Release 9.6.
are specified, the entire first label and the first 16 bits of
