9-2 DR-Z400EY (E-24 MODEL)

SPECIFICATIONS

DIMENSIONS AND DRY MASS
Overall length ................................................... 2 310 mm (90.9 in)
Overall width ....................................................
Overall height ................................................... 1 245 mm (49.0 in)
Wheelbase ....................................................... 1 475 mm (58.1 in)
Ground clearance ............................................
Seat height .......................................................
Dry mass ..........................................................
ENGINE
Type.................................................................. Four-stroke, liquid-cooled, DOHC
Number of cylinders ......................................... 1
Bore ................................................................. 90.0 mm (3.543 in)
Stroke ............................................................... 62.6 mm (2.465 in)
Piston displacement ........................................ 398 cm
Compression ratio ............................................ 12.2 : 1
Carburetor ........................................................ KEIHIN FCR39
Air cleaner ........................................................ Polyurethane foam element
Starter system.................................................. Electric
Lubrication system ........................................... Dry sump
TRANSMISSION
Clutch ............................................................... Wet multi-plate type
Transmission .................................................... 5-speed constant mesh
Gearshift pattern .............................................. 1-down, 4-up
Primary reduction ratio .................................... 2.960 (74/25)
Final reduction ratio ......................................... 3.357 (47/14)
Gear ratios, Low ............................................... 2.285 (32/14)
2nd ................................................ 1.733 (26/15)
3rd ................................................. 1.375 (22/16)
4th ................................................. 1.090 (24/22)
Top ................................................ 0.863 (19/22)
Drive chain ....................................................... RK520KZO, 112 links
825 mm (32.5 in)
315 mm (12.4 in)
935 mm (36.8 in)
127 kg (279 lbs)
3
(24.3 cu. in)
