1-8 GENERAL INFORMATION

SPECIFICATIONS

DIMENSIONS AND DRY MASS
Overall length .................................................. 2 235 mm (88.0 in)
Overall width .................................................... 825 mm (32.5 in)
Overall height .................................................. 1 245 mm (49.0 in)
Wheelbase ....................................................... 1 475 mm (58.1 in)
Ground clearance ............................................ 325 mm (12.8 in)
Seat height ....................................................... 945 mm (37.2 in)
Dry mass .......................................................... 113 kg (249 lbs) ..... DR-Z400
ENGINE
Type.................................................................. Four-stroke, liquid-cooled, DOHC
Number of cylinders ......................................... 1
Bore ................................................................. 90.0 mm (3.543 in)
Stroke ............................................................... 62.6 mm (2.465 in)
Piston displacement ........................................ 398 cm
Compression ratio ............................................ 12.2 : 1
Carburetor ........................................................ KEIHIN FCR39
Air cleaner ........................................................ Polyurethane foam element
Starter system.................................................. Primary kick .............. DR-Z400
Lubrication system ........................................... Dry sump
TRANSMISSION
Clutch ............................................................... Wet multi-plate type
Transmission .................................................... 5-speed constant mesh
Gearshift pattern .............................................. 1-down, 4-up
Primary reduction ratio .................................... 2.960 (74/25)
Final reduction ratio ......................................... 3.357 (47/14)
Gear ratios, Low ............................................... 2.285 (32/14)
2nd ................................................ 1.733 (26/15)
3nd ................................................ 1.375 (22/16)
4th ................................................. 1.090 (24/22)
Top ................................................ 0.863 (19/22)
Drive chain ....................................................... RK520KZO, 112 links
119 kg (262 lbs) ..... DR-Z400E
3 (24.3 cu. in)
Electric ...................... DR-Z400E
