A message indicating that the Product Activation Key was loaded
successfully appears. The red ERR LED on the Media card turns
OFF and the green RDY LED turns ON.
As no Default IP Network Service is defined, the system
automatically starts the Fast Configuration Wizard.
The Fast Configuration Wizard that is automatically started enables you
to configure the Default IP Service.
The IP Management Service tab in the Fast Configuration Wizard is enabled
only if the default Management IP addresses were not modified.
•
IPv4 is the default protocol for setting the Network Service in the
Fast Configuration Wizard.
•
If Secured Communication is required on the RMX: complete the
Fast Configuration Wizard, Login, install the Certificate and then
enable the Secured Communication Mode.
In the Fast Configuration Wizard - IP dialog box, define the following
1
parameters:
Field
IP Service
Name
Signaling Host
IP Address
Media Card 1/2/
3/4 IP Address
Subnet Mask
Click Next.
2

Initial System Configuration

Description
Use the default name (Default IP Service) or enter a name
using up to 20 characters.
Note: This field is displayed in all dialog boxes.
Enter the IP address of the Central Signaling host. This is
the address used by endpoints for dialing in to the MCU.
Enter the IP address(es) of the media card (s): MPMx 1,
MPMx 2, MPMx 3 and MPMx 4 (if installed), as provided
by the network administrator. Endpoints connect to
conferences and transmit call media (video, voice and
content) via these addresses.
Enter the subnet mask of the MCU.
Default value: 255.255.255.0.
7
