V ariable torque inverter
TM
TOSVERT
200V class
400V class 0.75 630kW
1.Make sure that this instruction manual is delivered to the end user of
the inverter unit.
2.Read this manual before installing or operating the inverter unit, and
store it in a safe place for reference.
PS1
VF-
0.4 90kW
NOTICE
E6581386
S afety
I
precautions
II II
I ntroduction
C ontents
1
R ead first
C onnection
2
equipment
3
O perations
S earching and
4
setting parameters
B asic
5
parameters
E xtended
6
parameters
O peration with
7
external signal
M onitoring the
8
operation status
M easures to
9
satisfy the
standards
S election of
10 10
peripheral
devices
T able of
11 11
parameters
12 12
S pecifications
B efore making a
13 13
service call
I nspection and
14 14
maintenance
15 15
W arranty
D isposal of
16 16
the inverter
