EP830 All-In-One EPIC Board User's Manual
 Timeout Value Range
 1 to 255
 Minute / Second
 Program Sample
Watchdog Timer can be set to system reset after 5-second timeout.
2E, 87
2E, 87
2E, 07
2F, 08
2E, 30
2F, 01
2E, F5
2F, N
2E, F6
2F, M
70
Logical Device 8
Activate
Set Minute or Second
N=08 (Min),00(Sec)
Set Value
M = 00 ~ FF
Watchdog Timer
