 Soft-Off by PWR-BTTN
This option only works with systems using an ATX power supply. It
also allows users to define which type of soft power OFF sequence
the system will follow. The default value is "Instant-Off".
This option follows the conventional manner of system
performance when turning the power to OFF. Instant-Off
Instant-Off
is a software power OFF sequence requiring the power
supply button is switched to OFF.
Upon the system's turning OFF through the power
switch, this option will delay the complete system power
OFF sequence approximately 4 seconds. Within this
Delay 4 Sec.
delay period, the system will temporarily enter into the
Suspend Mode enabling you to restart the system at
once.
 Power On by Ring
This option allows the system to resume or wake up upon detecting
any ring signals coming from an installed modem. The default
value is "Enabled".
 Resume by Alarm
If enable this item, the system can automatically resume after a
fixed time in accordance with the system's RTC (realtime clock).
** Reload Global Timer Events **
Global Timer (power management) events can prevent the system
from entering a power saving mode or can awaken the system from
such a mode.
 Primary/Secondary IDE 0/1
Use this item to configure the IDE devices monitored by the system.
 COM Port
Use this item to configure the COM ports monitored by the system.
 FDD, COM, LPT Port
Use this item to configure the FDD, COM and LPT ports monitored
by the system.
 PCI PIRQ[A-D]#
This item can be used to detect PCI device activities; if no activity,
the system will enter the sleep mode.
Press <Esc> to return to the Main Menu page.
