EP830 All-In-One EPIC Board User's Manual
Description
Pin
Data Carrier
1
Detect (DCD)
Receive Data
3
(RXD)
Transmit Data
5
(TXD)
Data Terminal
7
Ready (DTR)
9
Ground (GND)
2.4.15 Digital Visual Interface (DVI) Connector: DVI1
The EP830 Series has one connector that supports DVI/CRT. DVI1 is
a DVI connector for the DVI/CRT display.
DVI1: DVI-CRT VGA Connector
Pin
Description
1
TMDS Data 2-
3
GND
5
CRT_SPD_Data
7
DVI_SPD_Data
9
TMDS Data 1-
11
GND
13
N.C.
15
GND
17
TMDS Data 0-
19
GND
21
N.C.
23
TMDS Clock-
C1
Analog RED
C3
Analog Blue
C5
GND
28
Pin
Description
Data Set Ready
2
(DSR)
Request to Send
4
(RTS)
Clear to Send
6
(CTS)
8
Ring Indicator (RI)
10
NC
Pin
2
TMDS Data 2+
4
CRT_SPD_Clock
6
DVI_SPD_Clock
8
Analog Vsync
10
TMDS Data 1+
12
N.C.
14
+5V
16
Hot Plug Detect
18
TMDS Data 0+
20
N.C.
22
GND
24
TMDS Clock+
C2
Analog Green
C4
Analog Hsync
COM2, COM3, COM4
Description
Jumpers and Connectors
