EP830 All-In-One EPIC Board User's Manual

2.3.7

COM1 Mode Selection Jumpers: JP8, JP11,

JP14

These jumpers select the COM1 port's communication mode to

operate RS-232 or RS-422/485.

Description Function

COM1

RS-232

(Default)

RS-422

RS-485

Jumper Setting

JP14

JP8

JP14

JP8

JP14

JP8

Jumpers and Connectors

JP11
