Evaluation Board User Guide

QUICK START GUIDE

Follow these steps to quickly evaluate the
1. Install the system development platform (SDP) drivers.
2. Install the Int-N software.
3. Connect the SDP-S motherboard to the PC and to the EV-ADF4106SD1Z.
4. Follow the hardware driver installation procedure.
5. Connect the power supplies to banana connectors (6 V to 12 V).
6. Run the Int-N software.
7. Select the SDP board and the
8. Click the Main Controls tab. Update all registers.
9. Connect the spectrum analyzer to J2.
10. Measure the results.
ADF4106 device:
ADF4106 device in the Select Device and Connection tab of the software front panel window.
Rev. A | Page 3 of 24
UG-159
