4.

Installation

4.1

General

ATTENTION
(see chapter "Safety information and dan-
gers due to non-compliance")
The unit may only be installed by skilled per-
sonnel.
The chapter "Intended Use" must always be
observed!
The pipes must be able to safely support the
softener.
Otherwise mechanical damage or fractures/
bursts can occur in the pipes. This can result
in major water damage. People close to the
softener are exposed to a health risk due to
the large quantities of water released.
Therefore, if necessary, the pipes must be
additionally fixed or supported.
Always observe the given spacings to en-
sure convenient operation and servicing
(see chapter "Installed dimensions")
A clearance of at least 300 mm is required
above the softener in order to be able to
properly carry out all maintenance and ser-
vicing work.
(see chapter "Modifications / changes /
spare parts")
4.1.1 Requirements for the place of
installation
The room where the unit is installed must
be dry and frost free!
Unauthorised persons must not have ac-
cess to the softener!
ATTENTION
(see chapter "Safety information and dan-
gers due to non-compliance")
– The ambient temperature must not ex-
ceed 30°C (86°F)!
Installation
– In order to be able to safely discharge
the wastewater (regeneration) in opera-
tion and in case of any defects that occur
in the system, precise compliance with
the details given in the "Installation"
chapter is necessary!
– If the wastewater cannot be safely and
completely discharged, the house and
installations can be damaged by water.
– A shut-off valve must be installed up-
stream and downsteam of the softener
with a bypass to allow continued water
supply when the softener is out of ser-
vice! This enables the water supply to
the softener to be interrupted during in-
stallation, servicing/maintenance, re-
pairs and in case of malfunctions. Floods
and serious water damage to house in-
stallations can therefore be avoided.
– The unit can be installed in all standard
drinking water pipes.
– It is not permitted to install the softener
upstream of the water meter!
4.1.2 Installing position
(see chapter "Safety information and dan-
gers due to non-compliance")
Always install the softener in a vertical posi-
tion (± 5°)!
Failure to observe this can impair its func-
tion.
4.1.3 Power supply
JUDO QUICKSOFT-UNO
A power connection (230 V, 50
Hz), which is permanently live,
must be available.
ATTENTION
A splash proof socket is required
for the power pack, in accordance
with the legal regulations for wet
rooms.
