Attention:
Carefully read through the instal-
lation and operating instructions
and safety information before
installing and putting the unit into
service.
These Instructions must always
be issued to the owner/user.
Installation and Operating
Instructions
JUDO QUICKSOFT-DUO
Softener
Model JQS-D
Valid for: Canada
Fig. 1: JQS-D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Judo QUICKSOFT-DUO JQS-D
Summary of Contents for Judo QUICKSOFT-DUO JQS-D
- Page 1 Installation and Operating Instructions JUDO QUICKSOFT-DUO Softener Model JQS-D Valid for: Canada Attention: Carefully read through the instal- lation and operating instructions and safety information before installing and putting the unit into service. These Instructions must always be issued to the owner/user.
- Page 2 @ j u d o - o n l i n e . c o m Trademarks: Trademarks used in this document are protected and registered trademarks of the respective holder. © JUDO Wasseraufbereitung GmbH D-71351 Winnenden All rights reserved. Reprints – even of extracts – is only permitted with special written approval.
-
Page 3: Table Of Contents
11. Service Record Sheet ..... 31 the installation and instructions. 12. Customer Support ......32 Therefore, this instruction manual must always be read by the fitter / Installer and responsible skilled personnel/owner operator before installation, putting into service and maintenance. JUDO QUICKSOFT-DUO... -
Page 4: About This Operating Instructions
7 kPa = 0.0069 N/mm² – Rating plate 1" DN 25 – Cleaning information 1 Grain / US = 0.171 mmol/l alka- Gallon line earth ions must always be observed and kept in a fully legible condition. Fig. 2: Built-in rotary flange JUDO QUICKSOFT-DUO... -
Page 5: Intended Use
The softeners are only to be used in a tech- nically perfect condition, for their intended use, safely and aware of the dangers and with full observance of the instruction manual! JUDO QUICKSOFT-DUO... -
Page 6: Water Pressure
This can cause damage to operation. important functional interior parts of the controls. The optimum operating pressure for the softener lies between 44 psi (300 kPa) and 73 psi (500 kPa). It works most economically under these pressure conditions. JUDO QUICKSOFT-DUO... -
Page 7: Product Information
DIN 19636-100 (“softeners (Cation Exchangers) in Drinking Water Installa- tions”). All materials are hygienically and physiologically safe. Plastics fulfill the UBA (Umweltbundesamt / Federal Environmental Agency) KTW-Guideline DVGW Working Sheet W270. Metallic materials fulfil the requirements of DIN 50930-6. JUDO QUICKSOFT-DUO... -
Page 8: Installation
– The unit can be installed in all standard drinking water pipes. – It is not permitted to install the softener upstream of the water meter! A power connection (120 V / 60 Hz), which is permanently live, must be available. JUDO QUICKSOFT-DUO... - Page 9 It is suitable for both horizontal and vertical pipes. The installation height depends on the pipe layout. The minimum installation height from the floor to the rotary flange is 15 inches. JUDO QUICKSOFT-DUO...
- Page 10 Wall support without bypass valve Built-in rotary flange „R“ pipe flange „G“ unit flange Fig. 6: Bypass valve Wall support Fig. 8: Wall support with bypass valve For further information, please refer to the installation instructions for the wall support. JUDO QUICKSOFT-DUO...
- Page 11 The wastewater connection must not be located above the softener. An adequately dimensioned wastewater connection (e.g. floor drain) to DIN 1986 must be available for the wastewater and the back-up overflow hose (6). JUDO QUICKSOFT-DUO...
-
Page 12: Operation
(see chapter “Setting the – Mix in hard water using the setting screw raw water hardness”). of the blending valve (10) (see chapter – Open the water inlet. Open the bypass “Setting the blending”). valve. – Fit the cover (2). JUDO QUICKSOFT-DUO... - Page 13 DIP switch (21), contacts 1 to the DIP switch (21) is pushed down- 4 (see Fig. 11). wards. Raw water hardness tens digit Raw water hardness units digit DIP switch (20) DIP switch (21) Fig. 11: DIP switch JUDO QUICKSOFT-DUO...
- Page 14 Water Regulations of 1.1.2003 the limit value for sodium in drinking water is 200 mg/ l. This does not apply to mineral and table water. Their limit values are considerably higher, some have values above 1000 mg of sodium per litre. JUDO QUICKSOFT-DUO...
- Page 15 Operation 5.1.3 Control lamps, manual pushbuttons Fig. 12: Control lamps, manual pushbuttons Water flow rate yellow green Switch-over yellow Regeneration right green Trouble Regeneration left green Manual pushbutton to trigger regeneration JUDO QUICKSOFT-DUO...
-
Page 16: Functional Description
If a very high quantity of water is drawn off hygienically safe condition for weeks after (e.g. flush valve) and this leads to a pres- the regenerating salt shortage occurs. sure loss in the softener greater than around JUDO QUICKSOFT-DUO... -
Page 17: Modifications / Changes / Spare Parts
(28). position display (11). After two strokes the salting position (Pos 2) is reached. After approx. 3 minutes the drive executes a stroke again. Wastewater quantity up until then approx. 3.5 litres. JUDO QUICKSOFT-DUO... -
Page 18: Stoppages
The softener must be stored in a dry, frost- free place when dismantled. The connecting flange must be protected against dirt and damage. If the softener is refitted and put back into service, regeneration must always be carried out first (see chapter “Commis- sioning”). JUDO QUICKSOFT-DUO... -
Page 19: Faults
Without bypass facility: – Disconnect the power pack from the socket! (If installed, disconnect the power pack of the downstream metering pump too). – Immediately notify the fitter or nearest cus- tomer service (see chapter “Stoppages”). JUDO QUICKSOFT-DUO... -
Page 20: Maintenance
A servicing agreement is the best way to ensure a good operating function beyond the warranty period. Wherever possible, the regular servicing work and supply with consumables and wearing materials, etc. should be carried out by the specialist trade or the factory’s customer service department. JUDO QUICKSOFT-DUO... -
Page 21: Data Sheet
Data Sheet Operating weight when filled approx. with salt 60 kg Type Shipping weight approx. JUDO QUICKSOFT-DUO Softener 20 kg Abbreviated name: JQS-D Nominal flow rate up to 1.7 m³/h Order No.: 8200322 (7.5 gpm) Flow pressure at nominal 29 psi... -
Page 22: Diagrams
Fig. 13: Pressure loss in normal operating position Max. possible quantity drawn off daily depending on the raw water hardness and a mixed water hardness of approx. 10 °e. Raw water hardness [°e] Fig. 14: Amount drawn off daily JUDO QUICKSOFT-DUO... - Page 23 Raw water hardness [°e] Fig. 16: Wastewater quantity Salt consump- tion related to 1 m³ of mixed water with 10 °e depending on the raw water hardness. Raw water hardness [°e] Fig. 17: Salt consumption JUDO QUICKSOFT-DUO...
-
Page 24: Installed Dimensions
(approx. 10°e), zinced pipes and copper pipes can be laid. Our recommendation: Install a JUDO JULIA metering pump in the mixed water pipe downstream of the Softener, in order to proportionately enrich the water with a JUL mineral solution. -
Page 25: Jqs-D Spare Parts
JQS-D Spare Parts JQS-D Spare Parts JUDO QUICKSOFT-DUO... - Page 26 JQS-D Spare Parts JUDO QUICKSOFT-DUO...
- Page 27 JQS-D Spare Parts JUDO QUICKSOFT-DUO...
- Page 28 Cam-operated switch 2200713 Driving wheel 1120394 Setting: D, F, UK Electrical circuit 2200725 Casing 2201060 Unit No. O-Ring 5x2 1609461 Sleeve 1440122 Solenoid valve 1500209 Countersunk head tapping screw 2.9x22 1650194 Locking plate ***** 1400079 Operating cylinder 2200447 JUDO QUICKSOFT-DUO...
- Page 29 O-ring 53x3 1200185 O-ring 40x3 1200151 Driving slide ring 1420022 Driver 2200503 Wall support, complete 2200500 Rate regulator 1620213 Intake screen 1120021 O-ring 9.12 x3.53 1200251 VSV screw lower part 1120346 VSV sphere 2200565 Cheese head screw M5x80 1650195 JUDO QUICKSOFT-DUO...
- Page 30 2200579 166 Spare parts kit for injector 2200585 167 Spare parts kit for water meter 2200763 Replacement interval * = 1 year, ** = 2 years, *** = 3 years, **** = 4 years, ***** = 5 years JUDO QUICKSOFT-DUO...
-
Page 31: Service Record Sheet
Is completed by the customer service department (S = Total sum, L= extended salting period, N= normal regeneration, K = reduced salting period) b. Position 2 c. Position 3 d. Position 5 The values for intake time, wastewater produced, rinsing and initial filtrate apply to each regeneration stage. 1701743 JUDO QUICKSOFT-DUO... -
Page 32: Customer Service
Customer Service 12. Customer Service JUDO Water Treatment Inc. 240 Lesmill Road Toronto, ON M3B 2T5 phone: (866) 451-5836 (416) 451-1556 fax: (866) 761-3335 (416) 391-4275 e-mail: info@judo-online.com www.judo-online.com Installed by: All illustrations, dimensions and information for the different models are those valid on the date of prin- ting.
