If the connection for the wastewater sewer is
higher than this, the salt container can be
installed correspondingly higher with the aid
of a wall bracket (see chapter "Accesso-
ries").
ATTENTION
(see chapter "Safety information and dan-
gers due to non-compliance")
The wastewater connection must not be lo-
cated above the softener.
An adequately dimensioned wastewater
connection (e.g. floor drain) to DIN 1986
must be available for the wastewater and
the back-up overflow hose.
5.

Operation

ATTENTION
(see chapter "Safety information and dan-
gers due to non-compliance")
Always observe the chapter "Intended Use"!
5.1

Commissioning

The softener is connected to the water
system. The bypass valve is closed so that
the water by-passes the softener.
– Fill the regeneration salt into the salt
container (5). The water dissolves the
regeneration salt producing saturated
brine. The regeneration salt must at
least conform to food quality standards
and should fulfil the requirements ac-
cording to DIN EN 973.
– Our recommendation: Broxo or Solvay
salt, either as a block, tablets or coarse
grains 7 - 15 mm. If you use other regen-
erating salts, the salt container (5) must
be cleaned at shorter intervals and the
intake screen (88) replaced more often.
– Pour approx. 4 litres of water into the salt
container (5).
Operation
– Remove the cover (2).
– Enter the installation date on the label of
the operating cylinder (36) and in the
"servicing record sheet".
– Set the raw water hardness (
electrical circuit (see chapter "Setting the
raw water hardness").
– Open the water inlet. Open the bypass
valve.
For safety reasons the softener must be
vented immediately after it is connected to
the water system (bypass valve is open).
The system is automatically vented during
the first regeneration (see chapter "Com-
missioning").
– After each connection to the power sup-
ply the electronics automatically perform
a self-test for approx. 10 seconds. After
this has been successfully completed all
the control lamps briefly light up The sys-
tem control lamp (13) then lights up.
– Trigger regeneration manually: Press
the regeneration trigger (18). At the
same time you can check whether the
system is functioning correctly (see
chapter "Servicing/Repair").
After completing the regeneration the
softener is ready for use (approx.9 min-
utes).
The intake time should be at least 30
seconds (digit 2 can be seen on the driv-
ing wheel (11)). If the intake time is
shorter, water must be poured into the
salt container (5). Filled level 10 – 11 cm
above the floor of the container. Start a
new regeneration and check the intake
time.
– Mix in hard water using the setting screw
of the blending valve (10) (see chapter
JUDO QUICKSOFT-UNO
ATTENTION
Connect the softener to the
power supply. Plug the power
pack into the socket.
e) at the
°
