Therefore, this instruction manual must
always be read by the fitter and responsible
skilled personnel/owner or operator before
installation, commissioning and mainte-
nance.
Not only the general safety notes given in
the chapter "Intended Use"are to be
observed, but also the special safety
notes inserted under the other main
items.
1.1

Symbols used

The safety notes contained in this instruction
manual are labelled with the following
,
symbols:
ATTENTION
Warning, electrical voltage
Torques specified by the
manufacturer.
Tips for use and other
information.
Notes directly attached to the softener, e.g.
– direction of flow (see Fig. 1)
– rating plate
– cleaning information
must always be observed and kept in a fully
legible condition.
Fig. 1: Built-in rotary flange
About this Operating Instructions
Notes on
existing
dangers
JUDO QUICKSOFT-UNO
1.2 Safety information and dangers
due to non-compliance
In detail, failure to observe the general
danger symbols can result, for example, in
the following risks:
– failure of important functions of the
softener.
– danger to persons due to electrical and
mechanical effects.
– danger to persons and the environment
due to leaks.
Refrain from any unsafe working methods.
Failure to comply with this instruction
manual and the safety information can not
only result in dangers for people but can
also harm the environment and the unit.
1.3

Units used

In derogation of the International System of
Units (SI = System International), the
following units are used:
Units Conversion
°F °F = 9/5 °C + 32
1 bar = 10
bar
= 14.5 psi
1" DN 25
°e = 0.142 mmol/l
°e
alkaline earth ions
5 2
Pa = 0.1 N/mm
