Attention:
Carefully read through the instal-
lation and operating instructions
and safety information before
installing and putting the unit into
service.
These must always be issued to
the owner/user.
Installation and Operating
Instructions
JUDO QUICKSOFT-UNO
Softener
Valid for: EU countries and Switzerland
Language: English
Fig.: JQS-U

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QUICKSOFT-UNO and is the answer not in the manual?

Questions and answers

Related Manuals for Judo QUICKSOFT-UNO

Summary of Contents for Judo QUICKSOFT-UNO

  • Page 1 Installation and Operating Instructions JUDO QUICKSOFT-UNO Softener Valid for: EU countries and Switzerland Language: English Attention: Carefully read through the instal- lation and operating instructions and safety information before installing and putting the unit into service. These must always be issued to the owner/user.
  • Page 2 71364 Winnenden Germany Trademarks: Trademarks used in this document are protected and registered trademarks of the respective holder. © JUDO Wasseraufbereitung GmbH 71364 Winnenden Germany All rights reserved. Reprints – even of extracts – is only permitted with special approval.
  • Page 3 JUDO QUICKSOFT-UNO...

  • Page 4: Table Of Contents

    12. Customer Support ......32 specific regulations. Apart from the instruction manual and the legally binding accident prevention provi- sions applicable in the country and place of use, the recognized technical regulations for safe and proper work must also be observed. JUDO QUICKSOFT-UNO...

  • Page 5: Symbols Used

    – direction of flow (see Fig. 1) 1" DN 25 – rating plate °e = 0.142 mmol/l °e – cleaning information alkaline earth ions must always be observed and kept in a fully legible condition. Fig. 1: Built-in rotary flange JUDO QUICKSOFT-UNO...

  • Page 6: Intended Use

    The softeners are only to be used in a tech- nically perfect condition, for their intended use, safely and aware of the dangers and with full observance of the instruction manual! JUDO QUICKSOFT-UNO...

  • Page 7: Water Pressure

    This can cause damage to ation. important functional interior parts of the con- trols. The optimum operating pressure for the softener lies between 3 bar (43.5 psi) and 5 bar (72.5 psi). It works most econom- ically under these pressure conditions. JUDO QUICKSOFT-UNO...

  • Page 8: Product Information

    All materials are hygienically and creased energy consumption. physiologically safe. Plastics fulfil the official guideline of the German Federal Environ- mental Agency. Metallic materials fulfil the requirements of the DIN 50930-6 standard (Impact on the drinking water quality). JUDO QUICKSOFT-UNO...

  • Page 9: Installation

    A splash proof socket is required (see chapter “Safety information and dan- for the power pack, in accordance gers due to non-compliance”) with the legal regulations for wet – The ambient temperature must not ex- rooms. ceed 30°C (86°F)! JUDO QUICKSOFT-UNO...
  • Page 10 ATTENTION (see chapter “Safety information and dan- gers due to non-compliance”) wall support Fig. 6: Wall support with bypass valve Fig. 4: Built-in rotary flange For further information, please refer to the installation instructions for the wall support. JUDO QUICKSOFT-UNO...
  • Page 11 30° in an anti-clockwise direction. M6x25. – Position it on the bulit-in rotary flange so that the screw heads pass through the Select the torque (approx. 4 Nm) so bayonet fixing drill holes (see Fig. 7 I). that the gasket closes! JUDO QUICKSOFT-UNO...
  • Page 12 Do not grasp into the connection flange kinks. of the device after removing the white protective disc (danger of violent pres- sure)! JUDO QUICKSOFT-UNO...

  • Page 13: Operation

    (88) replaced more often. time. – Pour approx. 4 litres of water into the salt – Mix in hard water using the setting screw container (5). of the blending valve (10) (see chapter JUDO QUICKSOFT-UNO...
  • Page 14 To set the English hardness the contact 8 of (see Fig. 10). the DIP switch (21) is moved to the position opposite to „ON“. Raw water hardness tens digit Raw water hardness units digit DIP switch (20) DIP switch (21) Fig. 10: DIP switch JUDO QUICKSOFT-UNO...
  • Page 15 200 mg/l. This does not ap- ply to mineral and table water. Their limit val- ues are considerably higher, some have val- ues above 1000 mg of sodium per litre. JUDO QUICKSOFT-UNO...

  • Page 16: Functional Description

    As the whole regener- ation including rinsing out the used brine on- ly takes around 9 minutes, this typical prop- erty of a single column system is hardly noticeable. JUDO QUICKSOFT-UNO...

  • Page 17: Salt Fill

    The brine stocks still available are primarily cutes a stroke again. Wastewater quan- used for disinfecting the ion exchange resin tity up until then approx. 3.5 litres. and the softening effect is reduced. – After this stroke the "Backwash" position JUDO QUICKSOFT-UNO...

  • Page 18: Stoppages

    Strictly com- ply with the instructions given in the “Installation” and “Maintenance” chapters. Disconnect the power pack from the socket! (If installed, disconnect the power pack of the downstream metering pump too!) JUDO QUICKSOFT-UNO...

  • Page 19: Faults

    Without bypass facility: – Disconnect the power pack from the socket! (If installed, disconnect the pow- er pack of the downstream metering pump too). – Immediately notify the fitter or nearest customer service (see chapter “Stoppag- es”). JUDO QUICKSOFT-UNO...

  • Page 20: Maintenance

    En- sure that the salt solution container is not overfilled and that it is carefully closed again at the end of the work. Part packages are to JUDO QUICKSOFT-UNO...

  • Page 21: Data Sheet

    Data Sheet Data Sheet Operating weight when filled approx. 55 with salt Type Shipping weight approx. JUDO QUICKSOFT-UNO softener 13.8 kg Abbreviated name: JQS-U Nominal flow rate up to 1.0 m³/h Order No.: 8200319 Flow pressure at nominal 2 bar...

  • Page 22: Diagrams

    Fig. 13: Pressure loss in normal operating position Max. possible quantity drawn off daily depending on the raw water hardness and a mixed water hardness of approx. 10 °e. Raw water hardness [°e] Fig. 14: Amount drawn off daily JUDO QUICKSOFT-UNO...
  • Page 23 Wastewater quantity related to 1 m³ of mixed water with 10 °e depending on the raw water hardness. Raw water hardness [°e] Fig. 15: Wastewater quantity Salt consumption related to 1 m³ of mixed water with 10 °e depending on the raw water hardness. Raw water hardness [°e] Fig. 16: Salt consumption JUDO QUICKSOFT-UNO...

  • Page 24: Installed Dimensions

    – Bypass valve JQX (order no. 8735210) – Hardness measuring equipment JGHP 0-37.5°e (order no. 8742120) – Extension quick set JQR for series con- nection of two JUDO units (e.g. filter and softener) to a pipe connection (order no. 8250041) – Wall bracket for salt container (order no.

  • Page 25: Jqs-U Spare Parts

    JQS-U Spare Parts JQS-U Spare Parts 28 23 21 20 JUDO QUICKSOFT-UNO...
  • Page 26 JQS-U Spare Parts JUDO QUICKSOFT-UNO...
  • Page 27 JQS-U Spare Parts JUDO QUICKSOFT-UNO...
  • Page 28 Setting: Raw water hardness units digit / Language setting: D, F, UK Cam-operated switch 2200713 Driving wheel 2201429 Electronic control 2201448 Casing 2200855 Unit no. O-ring 5x2 1609461 Sleeve 1440122 Solenoid 1500522 Countersunk head tapping screw 2.9x22 1650277 Locking plate ***** 1400079 Drive cylinder JUDO QUICKSOFT-UNO...
  • Page 29 O-ring 40x3 1200151 Driving slide ring 1420022 Driver 2201079 Wall support, complete 2200500 Rate regulator 1620213 Intake screen 2201270 O-ring 9.12 x3.53 1200251 Blending valve screw lower part 1120346 Blending valve cone 2200565 Cheese head screw M5x80 1650195 JUDO QUICKSOFT-UNO...
  • Page 30 166 Spare parts kit for injector 2200585 167 Spare parts kit for water meter 2200763 1) AU = Accounting unit Replacement interval * = 1 year, ** = 2 years, *** = 3 years, **** = 4 years, ***** = 5 years JUDO QUICKSOFT-UNO...

  • Page 31: Service Record Sheet

    1) Is completed by the customer service department (S = Total sum, L = extended salting period, N = normal regeneration, K = reduced salting period) 2) Position 2 3) Position 3 4) Position 5 The values for intake time, wastewater produced, rinsing and initial filtrate apply to each regeneration stage. JUDO QUICKSOFT-UNO...

  • Page 32: 12. Customer Support
