4.
Installation
4.1
General
ATTENTION
(see
chapter
"Safety
dangers due to non-compliance")
The unit may only be installed by skilled
personnel.
The chapter on "Intended Use" must always
be observed!
The pipes must be able to safely support the
softener.
Otherwise mechanical damage or fractures/
bursts can occur in the pipes. This can result
in major water damage. People close to the
softener are exposed to a health risk due to
the large quantities of water released.
Therefore, if necessary, the pipes must be
additionally fixed or supported.
Always observe the given spacings to
ensure convenient operation and servicing
(see chapter "Installed dimensions")
A clearance of at least 300 mm (12 inches)
is required above the softener in order to be
able to properly carry out all maintenance
and servicing work.
(see chapter "Modifications / changes /
spare parts")
8
Installation
information
and
JUDO QUICKSOFT-DUO
4.1.1 Requirements for the place of
installation
The room where the unit is installed must
be dry and frost free!
Unauthorised persons must not have
access to the softener!
ATTENTION
(see
chapter
"Safety
dangers due to non-compliance")
– The ambient temperature must not
exceed 30 °C (86 °F)!
– In order to be able to safely discharge
the wastewater (regeneration) in opera-
tion and in case of any defects that occur
in the system, precise compliance with
the details given in the "Installation"
chapter is necessary!
– If the wastewater cannot be safely and
completely discharged, the house and
installations can be damaged by water.
– A shut-off valve must be installed
upstream
and
softener
with
continued
water
softener is out of service! This enables
the water supply to the softener to be
interrupted during installation, servicing/
maintenance, repairs and in case of
malfunctions. Floods and serious water
damage to house installations can there-
fore be avoided.
– The unit can be installed in all standard
drinking water pipes.
– It is not permitted to install the softener
upstream of the water meter!
A power connection (120 V / 60 Hz),
which is permanently live, must be
available.
information
and
downsteam
of
a
bypass
to
allow
supply
when
the
the
