supplement DIN 1988ff. as well as DIN EN
1717.
It has been tested and certified by the
DVGW (Deutsche Vereinigung des Gas-
und Wasserfaches e. V. - Technisch-wis-
senschaftlicher Verein) in accordance with
the requirements
• of the DIN EN 13443-1 and DIN 19628
for mechanically active filters.
The device bears the DVGW mark as proof
of certification.
Only devices with a standard sieve
INFO_NO_HEADER
mesh width of 0.1 mm carry the
DVGW test mark. Devices with
the available special mesh widths
0.03 mm, 0.32 mm and 0.5 mm
are not part of the test according to
DIN EN 13443-1 and DIN 19628 and
are therefore not permitted to wear
the approval mark.
3

Installation

CAUTION
The device may only be installed
by qualified technical personnel.
Installation of the device upstream of the
water meter is forbidden.
3.1

Conditions

CAUTION
Risk of property damage or water
damage!
The pipe must be able to safely
support the device (weight: see
chapter 7). If necessary, the pipes
must be provided with additional
fastenings or support.
8
Installation
To ensure convenient operation and main-
tenance of the device, always adhere to the
specified clearances in chapter 3.4.1.
3.1.1 Requirements for the place of
installation
CAUTION
The installation room must be dry
and free from frost.
The ambient temperature must not
exceed 30 °C! In higher temper-
atures or direct sunlight, mater-
ial damage may occur up to and
including breakage of device
parts.
An adequately sized waste water
connection (e.g. floor drain) in
compliance with DIN 1986 must be
provided.
3.2 Installation of the rotary
flange fitting
CAUTION
The flange surface of the rotary
flange fitting must be upright!
The rotary flange fitting must
be fitted so that it is free from
mechanical stress or strain. Oth-
erwise mechanical damage to the
pipe or the rotary flange fitting up
to and including breaks can result.
The built-in rotary flange serves as a con-
necting element between the domestic
water station and the device. It is suitable
both for horizontal and vertical pipes.
Attention: Install the built-in rotary flange
in the flow direction! This is indicated by an
arrow integral with the casting.
If the installation is twisted, back-
INFO_NO_HEADER
washing the device is not possible.
JUDO JPF+ 1701582 • 2018/12
