9.
Data Sheet
9.1
Type
JUDO QUICKSOFT-UNO softener
Abbreviated name: JQS-U
Order No.: 8200319
9.2
Technical specifications
– Maximum ambient temperature and wa-
ter temperature: 30°C (86°F)
– The water to be softened must con-
form to the European Drinking Water
Regulations!
– Threaded connection to DIN 2999.
Operating pressure
2 – 7 bar (29 - 101.5 psi) PN 10
The nominal pressure denotes the pressure
class, according to which the softener must
fulfil the requirements to DIN EN 14743 and
DIN 19636-100. The maximum operating
pressure is lower, in order to ensure the op-
timum function of the softener.
Data Sheet
Nominal pressure
JUDO QUICKSOFT-UNO
Operating weight when filled
with salt
Shipping weight
Nominal flow rate up to
Flow pressure at nominal
flow rate at least
Pressure loss at nominal
flow rate
Short-term max. flow
Pipe connection
Nominal capacity
Capacity per kg regenerat-
ing salt
Salt container capacity
Electrical connection
Power consumption
Operation
Regeneration
For further information,
please refer to the "Dia-
grams" chapter.
approx. 55
kg
approx.
13.8 kg
1.0 m³/h
2 bar
(29 psi)
1 bar
(14.5 psi)
3.5 m³/h
1"
0.45 mol
5 mol
40 kg
230 V/ 50
Hz
1 W
max. 15 W
21
