Summary of Contents for Wirepath Surveillance WPS-750-BUL-IP

  • Page 1 WPS-750-BUL-IP IP Bullet Camera Installation and User’s Manual Review manual thoroughly before installation. Retain for future reference.

  • Page 3: 1- Safety Instructions

    WPS-750-BUL-IP Installation Manual 1- Safety Instructions Read and follow all instructions and warnings in this manual. Keep for future reference. Install according to manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat.

  • Page 4: Table Of Contents

    WPS-750-BUL-IP Installation Manual Table of Contents 1- Safety Instructions ........................3 2- Manual Overview .......................... 7 3- Required Items for Installation ....................8 4- Package Contents ......................... 8 5- Optional Accessories ........................8 5.1-Mounts ..........................8 5.2-• Power Supplies ........................9 6- Camera Overview ..........................
  • Page 5 WPS-750-BUL-IP Installation Manual 11- Additional Configuration ......................20 1-Upgrade the Firmware ......................20 2-Configure a Privacy Mask ...................... 20 3-Configure Motion Detection Areas ..................21 4-Setup a Schedule ........................21 5-Configure Camera for Remote Access .................. 22 12- Configuration Menu Operation ....................23 12.1-System Information ......................
  • Page 6 WPS-750-BUL-IP Installation Manual 12.11.1-Motion Detection ..........................38 12.11.2-Record File ............................. 38 12.11.3-Record Time Setting ........................39 12.11.4-Network Disconnected ........................39 12.11.5-Network IP Check ........................... 39 12.12-Schedule ........................39 12.13-I/O Settings ........................40 12.13.1-Input Settings..........................40 12.13.2-Output Settings ..........................40 12.14-Log List ........................... 40 12.15-SD Card ..........................

  • Page 7: 2- Manual Overview

    WPS-750-BUL-IP Installation Manual 2- Manual Overview We recommend that this document is read in its entirety before proceeding with system design, installation, or operation of the WPS- 750-BUL-IP camera. When viewing this document electronically, the content identified within references can be quickly located by clicking on the reference.

  • Page 8: 3- Required Items For Installation

    WPS-750-BUL-IP Installation Manual 3- Required Items for Installation The following items are required during the installation of a Wirepath™ IP Camera. It is recommended that these items are prepared in advance to ensure that the installation can be performed smoothly.

  • Page 9: Power Supplies

    WPS-750-BUL-IP Installation Manual 5.2- • Power Supplies Local Power Supplies  PS-12DC-1A 12 Volt 1 Amp Power Supply for Cameras & IR Systems Remote Power Supplies Use these remote power supplies to power all the cameras in the system from a remote location.

  • Page 10: 6- Camera Overview

    WPS-750-BUL-IP Installation Manual 6- Camera Overview 6.1- Features  2 MegaPixel 16x9 CMOS sensor This camera sports a 2MP 16x9 CMOS sensor that provides improved picture quality over a typical CCD sensor. Supports full 1080HD up to 1920x1080 at 30FPS.

  • Page 11: Camera Connections

    WPS-750-BUL-IP Installation Manual 6.2- Camera Connections Ethernet Connection (RJ45) 568-B Connect to network switch for communication to and from the camera. Pin out follow EIA standard 12V DC Power In (Barrel Connector) Connect to a 12V DC 1A power supply. The camera is not supplied with a power supply, see section 5.2-Power Supplies...

  • Page 12: Main Camera Interface

    WPS-750-BUL-IP Installation Manual 6.3- Main Camera Interface Note: The camera requires configuration before accessing for the first time. See sections 9-IP Installer Software Initial Configuration before opening the browser. 6.3.1- Accessing the Camera Note: IE 8.0 or higher is required to access the camera; other browsers are not supported at this time.

  • Page 13: 3-Live View Controls

    WPS-750-BUL-IP Installation Manual 6.3.3- Live View Controls 6.3.3.1- Top of Screen Video Expands the camera’s image to full screen. Press ESC or double click on full screen image to return to Live View screen. Digital Zoom Select the checkbox to enable Digital Zoom.

  • Page 14: 7- System Diagram Considerations

    WPS-750-BUL-IP Installation Manual 7- System Diagram Considerations 7.1- Recommended Equipment 7.1.1- Power Supplies Wirepath™ Surveillance IP Cameras can be power using PoE (Power over Ethernet) which supplies power via the Cat5e/Cat6 Ethernet connection. We recommend this method be used as it limits the amount of wiring required thus drastically reducing installation time.

  • Page 15: 8- Camera Installation

    WPS-750-BUL-IP Installation Manual 8- Camera Installation 1- Prepare Camera for Mounting Prior to mounting to the Camera, we recommend that the position and angles be preset in order to reduce configuration time. These settings can be fine-tuned once the Camera is mounted.

  • Page 16: 3-Mount The Camera

    WPS-750-BUL-IP Installation Manual +5V DC 50mA max N.O. – Trigger on contact closure N.C. – Trigger on contact open GND Ground Open: +5V DC 50mA max Closed: 0V DC 3- Mount the Camera Tip: Before mounting the Camera, write down the Cameras Mac Address, Model Number, and location. These will come in handy during setup or if troubleshooting is required.

  • Page 17: 9- Ip Installer Software

    WPS-750-BUL-IP Installation Manual 9- IP Installer Software The IP Installer software provides a quick view of Wirepath™ IP Surveillance devices connected to local network. This software is required for initial setup of any Wirepath™ IP Surveillance device. Recommendation: Before starting any configuration or service of Wirepath™ IP devices, we recommend that the latest version of the IP Installer is downloaded from www.SnapAV.com to ensure that all functionality is available.

  • Page 18: 10- Initial Configuration

    WPS-750-BUL-IP Installation Manual 10- Initial Configuration 1- Assign a Static IP address By default the Camera will receive an IP address via DHCP; however, it is recommended that the Camera is assigned a static IP address, and given a 4 digit port. Using a static IP address ensures that the address will not change due to changes to the router.

  • Page 19: 6-Change The Administrator Password

    WPS-750-BUL-IP Installation Manual 6- Change the Administrator Password Now that the camera is visible on the network, we recommend that the administrator password is changed from the default to prevent unwanted access. See section 12.2-User Management for details on the features used in this step.

  • Page 20: 11- Additional Configuration

    WPS-750-BUL-IP Installation Manual 11- Additional Configuration Recommendation: While the camera can be configured remotely from outside the local network, operation can be slow. We strongly recommend that the bulk of configuration be performed via the local network to avoid slow response times.

  • Page 21: 3-Configure Motion Detection Areas

    WPS-750-BUL-IP Installation Manual 3- Configure Motion Detection Areas Motion Detection allows for specific areas of the image to be used for triggering the recording of video, an alarm, or sending a notification. When an area is defined, motion in that area will trigger the predefined action; this is useful to avoid unwanted events from being triggered due to motion in areas of no concern.

  • Page 22: 5-Configure Camera For Remote Access

    WPS-750-BUL-IP Installation Manual D. In the Snapshot section, select the delivery method for the Snapshot. Select an Interval between the Snapshots for the selected periods. Example: when set to 60 seconds, a snapshot will be sent to the selected destinations every 60 seconds.

  • Page 23: 12- Configuration Menu Operation

    WPS-750-BUL-IP Installation Manual 12- Advanced Menu Configuration 12.1- System Information This menu displays important information about the camera’s network settings, and allows for setting items such as language, Date, and Time. 12.1.1- Server Information Displays information about the Camera’s MAC Address, allows for entering a name to easily identify the Camera, and selecting a language for the GUI.

  • Page 24: 3-Time Settings

    WPS-750-BUL-IP Installation Manual 12.1.3- Time Settings Proper time settings are important for producing accurate time stamps for events, recorded video, and captured snapshots. Server Time Displays the Current Time and Date for the Cameras Date Format Select the desired format to display the Date.

  • Page 25: System Update

    WPS-750-BUL-IP Installation Manual 12.3- System Update Important Note: Updating Firmware MUST be performed over a wired IP connection to the device. While it is possible to recover from an upgrade that fails due to a lost or intermittent connection, the camera will be inoperable until it is recovered via a reliable connection.

  • Page 26: Ip Settings

    WPS-750-BUL-IP Installation Manual 12.4- IP Settings 12.4.1- IP Assignment Allows for configuration of the Camera’s network settings for IP communication. We recommend that this information is provided by the network administrator to avoid address conflicts with other devices on the network.

  • Page 27: 3-Upnp Settings

    WPS-750-BUL-IP Installation Manual 12.4.3- UPnP Settings When enabled, UPnP (Universal Plug and Play) allows the camera to appear under the PC network devices. To use this feature, UPnP must be enabled on the PC. Also contains settings for UPnP Port forwarding for use with compatible routers.

  • Page 28: 8-Lltd (Link Layer Topology Discovery)

    WPS-750-BUL-IP Installation Manual 12.4.8- LLTD (Link Layer Topology Discovery) When enabled, the Cameras connection status and properties can be viewed in a PCs network map. The PC must support LLTD in order to use this feature. See section 18.4-LLTD (Link Layer Topology Discovery) for more details.

  • Page 29: Advanced Ip Settings

    WPS-750-BUL-IP Installation Manual 12.5- Advanced IP Settings 12.5.1- HTTPS Settings Accessing the Camera through HTTPS provides an additional security level for the video stream by requiring certificate authentication. Subject Display the Subject Content of the certificate Date Date the certificate was created.

  • Page 30: Pppoe & Ddns Settings

    WPS-750-BUL-IP Installation Manual 12.6- PPPoE & DDNS Settings 12.6.1- PPPoE Settings Point-to-Point Protocol Over Ethernet (PPPoE) is a network protocol primarily used DSL (Digital Subscriber Line) providers and modems. This protocol requires a login to connect to the modem even when a router is used.

  • Page 31: Server Settings

    WPS-750-BUL-IP Installation Manual 12.7- Server Settings A “server” in this case is an Email account, FTP site or Samba network share, each of which must be configured in order to send or save notifications, snapshots or short video recordings. While all methods can be used, only Email is needed for notifications.

  • Page 32: 2-Ftp Settings

    WPS-750-BUL-IP Installation Manual 12.7.2- FTP Settings When an FTP server is configured, recorded video and snapshot files can be stored on the server for later access. Contact the network administrator for FTP server information. FTP Site address. This is usually the same as one would use to access the FTP Server FTP site from a browser or FTP client.

  • Page 33: Image Settings

    WPS-750-BUL-IP Installation Manual 12.8- Image Settings While the default settings will work in most cases, the conditions at the location of the Camera may require tweaking to ensure that the image is clear and accurate. Use this menu to adjust the image for daytime, or nighttime, and adjust the image parameters.
  • Page 34 WPS-750-BUL-IP Installation Manual Changes the orientation of the image based on the mounting method. Default is Video configured for standard mounting from a ceiling or eave. Select Flip or Mirror to Orientation change the orientation of the image. Select Day and Night settings for the camera: Day &...

  • Page 35: Video Settings

    WPS-750-BUL-IP Installation Manual 12.9- Video Settings The Camera supports up to 4 streams that can be used for streaming to a mobile device, network recorder, control system GUI, or the browser GUI simultaneously. While the highest quality is desired, it may not be supported by the network or device, and will also have a larger storage size.

  • Page 36: 2-Streaming 3

    WPS-750-BUL-IP Installation Manual Video Bitrate Advanced Mode Only: Sets the fixed bitrate to use when CBR is selected for bitrate control. While many intermediate settings exist, recommend setting to 1, 2, 4, 6 or 8 Mbps for compatibility with Wirepath™ NVRs.

  • Page 37: Audio Settings

    WPS-750-BUL-IP Installation Manual 12.10- Audio Settings Use this menu to configure Audio if the Camera has a microphone installed. IP Camera to When enabled, allows audio from a microphone (ex: WPS-ACC-MIC) installed at the Camera to be heard at the PC.

  • Page 38: Event Settings

    WPS-750-BUL-IP Installation Manual 12.11- Event Settings 12.11.1- Motion Detection Provides up to 3 areas to select for detecting motion on the camera. When configured, an action such as recording video, taking a snapshot or series of snapshots, and/or sending email notification can be performed after the motion is detected.

  • Page 39: 3-Record Time Setting

    WPS-750-BUL-IP Installation Manual 12.11.3- Record Time Setting Pre Alarm Amount of time prior to the event to start the recording, from 0-5 seconds. Post Alarm Amount of time after to the event to stop the recording, from 0-10 seconds. Note: The camera cannot currently record for the entire time of a motion event.

  • Page 40: I/O Settings

    WPS-750-BUL-IP Installation Manual 12.13- I/O Settings Use this menu to configure the Cameras Contact & Relay connections. 12.13.1- Input Settings DI Sensor State Camera expects contact closure connected to the DI input to be normally Open. An Event is triggered when the contact is closed.

  • Page 41: Sd Card

    WPS-750-BUL-IP Installation Manual 12.15- SD Card Use this menu to set the amount of days of recording to store on an installed SD Card. Displays “No SD Card” when no microSD card is installed. Playback When a microSD card is installed and the card contains media, displays folder names consisting of dates when media was saved.

  • Page 42: 13- Mobile App Access

    WPS-750-BUL-IP Installation Manual 13- Mobile App Access FREE Use your computer, or iPhone®, native iPad®, or Android, Smartphone Apps to view cameras while at the office or on the go. Details on setup and operation can be found @ www.SnapAV.com.

  • Page 43: 14- Specifications

    WPS-750-BUL-IP Installation Manual 14- Specifications Imaging 1/2.7” 2MP CMOS sensor Image sensor Lens Type Vari-focal 3.3~12mm Mega Pixel Lens F1.4 Video Resolution 1920x1080@30fps, 1280x720@30fps, 640x480@30fps, 320x240@30fps, 176x144@30fps 0.5 lux @F1.4 (IR off) Minimum Illumination 0 lux @F1.4 (IR on) DC IRIS...
  • Page 44 WPS-750-BUL-IP Installation Manual Technology Image Adjustment Brightness, Contrast, Hue, Saturation, Sharpness Sense Up Digital WDR 2D DNR Sense Up Flip Mirror Shutter Speed Adjustable Day&Night Adjustable Quad Streaming Image Snapshot Full Screen Monitoring Privacy Mask Video Compression format H.264/ M-JPEG/ MPEG4...
  • Page 45 WPS-750-BUL-IP Installation Manual Input/Output Ports Video Test Port Setup Power Port On Pigtail 1 Digital in and 1 Digital out (3pin Green Socket), DC-jack, 1 Audio in and 1 Audio out, male RJ45 Audio Audio Compressioin G.711(64K) and G.726(32K,24K) audio compression Audio Input 3.5mm x 1...
  • Page 46 WPS-750-BUL-IP Installation Manual Certifications Onvif CE, FCC, RoHS Pg. 46 © 2013 Wirepath™ Surveillance...

  • Page 47: 15- Dimensions

    WPS-750-BUL-IP Installation Manual 15- Dimensions 9.07in. 8.39in. 3.24in. 3.73in. 0.6in. Ø 3.06in. Pg. 47 www.snapav.com Support: 866.838.5052...

  • Page 48: 16- Warranty

    WPS-750-BUL-IP Installation Manual 16- Warranty 3-Year Limited Warranty This Camera has a 3-Year Limited Warranty. The warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified, disassembled or improperly installed.

  • Page 49: 18- Technical Information Glossary

    WPS-750-BUL-IP Installation Manual 18- Technical Information Glossary 18.1- Constant vs. Variable Bit Rate IP cameras record light from a scene coming through a lens focused onto a sensor, and the image is converted into a digital format by a processor to be streamed out over a network for viewing or recording. The amount of information converted by the processor increases as the image becomes more complex.

  • Page 50: Lltd (Link Layer Topology Discovery)

    WPS-750-BUL-IP Installation Manual 18.4- LLTD (Link Layer Topology Discovery) LLTD, or Link Layer Topology Discovery, is a technology used by Windows operating system to automatically discover devices on a network without having to know any information. When properly configured on the computer and the network device, LLTD will allow a user to find the new device on a map of the network in Windows Network Settings.
  • Page 52 © 2013 Wirepath™ Surveillance 130304-1248...
