- Page 1 WPS-300-BUL-A-GR WPS-300-BUL-A-WH BULLET CAMERA INSTALLATION MANUAL Review manual thoroughly before installation. Retain for future reference.
-
Page 2: Table Of Contents
WPS-300-BUL-A Installation Manual CONTENTS Safety Instructions ..................3 Features.......................4 Package Contents ..................4 Installation Instructions ................5 Troubleshooting ..................7 Dimensions ....................8... -
Page 3: Safety Instructions
5. Do not install the camera in environments with extreme humidity. Installing camera in environments with extreme humidity may cause moisture to condense on the surface of the lens or dome cover, which can affect picture quality. © 2012 Wirepath Surveillance... -
Page 4: Features
WPS-300-BUL-A Installation Manual FEATURES • 1/3” Sony Super HAD II CCD The Sony Super Had II CCD is ideal for low lux illumination resulting in a clear and crisp image. • Varifocal Lens This camera features a varifocal lens with a focal length of 4-9mm to offer flexibility during installation. -
Page 5: Installation Instructions
3. Using the DC plug supplied, connect the power supply jack to 12V DC and the BNC Video Output DC Plug to the desired video line. 12V DC Power BNC Video Output © 2012 Wirepath Surveillance... - Page 6 WPS-300-BUL-A Installation Manual 4. Once the camera is installed, check the viewing angle, zoom and focus settings. The camera is supplied with a BNC Test Adapter that allows for viewing the output of the camera on a monitor or the WPS-CCTV-TESTER. Use this connection to adjust the camera directly from the installed location.
-
Page 7: Troubleshooting
• Check the color of the beads in the Silica pack under the lens cover. • If the blue crystals have turned pink indicating that the pack has absorbed moisture, replace the pack with the spare provided with the camera. © 2012 Wirepath Surveillance... -
Page 8: Dimensions
WPS-300-BUL-A Installation Manual SPECIFICATIONS WPS-300-BUL-A Wirepath™ Surveillance IR Outdoor Varifocal Bullet Camera (550 TVL) Image Sensor 1/3" Color Sony Super HAD II Number of Pixels NTSC:768(H)x494(V) Lens 4~9mm Auto Iris Vari-Focal Lens, Horizonal FOV 60˚(W)~30˚(T) Shutter Control <NTSC>1/60~1/100,000 sec; <PAL>1/50~1/100,000 sec Auto Electronic Shutter Auto Gain Control Back Light Compensation... - Page 9 WPS-300-BUL-A Installation Manual DIMENSIONS © 2012 Wirepath Surveillance...
- Page 10 Products to be repaired under this warranty must be returned to Wirepath™ Surveillance or a designated service center with prior notification and an assigned return authorization number (RA). CONTACTING TECHNICAL SUPPORT Phone: (866) 838-5052 Email: Techsupport@snapav.com 121019-1650 © 2012 Wirepath Surveillance...
