WPS-300-CUB-IP
IP CUBE
CAMERA
INSTALLATION MANUAL
Review manual thoroughly before installation.
Retain for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPS-300-CUB-IP and is the answer not in the manual?

Questions and answers

Related Manuals for Wirepath Surveillance WPS-300-CUB-IP

Summary of Contents for Wirepath Surveillance WPS-300-CUB-IP

  • Page 1 WPS-300-CUB-IP IP CUBE CAMERA INSTALLATION MANUAL Review manual thoroughly before installation. Retain for future reference.

  • Page 2: Safety Instructions

    WPS-300-CUB-IP Installation Manual 1. Safety Instructions Read and follow all instructions and warnings in this manual. Keep for future reference. Install according to manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat.

  • Page 3: Table Of Contents

    WPS-300-CUB-IP Installation Manual Table of Contents 1. Safety Instructions 2. Introduction 2.1. Features 3. Package Contents 4. Required Items for Installation 5. How It Works 5.1. Device Layout 6. Assembling and Mounting Your Camera 7. Connecting Your Camera 7.1. Essential Connections — Network and Power 7.1.1.

  • Page 4: Streaming

    WPS-300-CUB-IP Installation Manual 9.2. System Information and Settings 9.2.1. System Information Menu Settings 9.2.1.1. Server Information 9.2.1.2. OSD Setting 9.2.1.3. Time Setting 9.2.1.4. Network LED 9.2.2. Camera Time Setup 9.2.2.1. NTP Time 9.2.2.2. Synchronize With PC’s Time 9.2.2.3. Manual 9.2.2.4. Internal Clock 9.2.2.5.
  • Page 5 WPS-300-CUB-IP Installation Manual 9.3.5. Advanced IP Settings - QoS/DSCP 9.3.5.1. QoS / DSCP Setting 9.3.6. PPPoE Setup 9.3.6.1. PPPoE Overview 9.3.6.2. PPPoE Settings 9.3.6.3. Send Mail after PPoE Dialed 9.3.7. DDNS Setup 9.3.7.1. DDNS Overview 9.3.7.2. DDNS Settings 9.3.7.3. State (DDNS) 9.3.7.4.
  • Page 6 WPS-300-CUB-IP Installation Manual 9.5.3.1. Snapshot Menu 9.5.3.2. How to Set Up Scheduling for Events 9.5.3.3. Set up Snapshot 9.6. Log List 9.6.3.1. System Log 9.6.3.2. Motion Detection Log 9.6.3.3. All Logs 9.7. SD Card Menu 9.7.1. Playback 9.7.2. SD Management 10.

  • Page 7: Introduction

    WPS-300-CUB-IP Installation Manual 2. Introduction Thank you for purchasing a Wirepath™ IP Surveillance camera. The WPS-300-CUB-IP is an indoor cube-style camera meant for mounting to any wall, ceiling or surface, for easy monitoring over a web or smartphone interface. We recommend that this document be read in its entirety before proceeding with system design, installation, or operation of the camera.

  • Page 8: Package Contents

    WPS-300-CUB-IP Installation Manual 3. Package Contents • (1) WPS-300-CUB-IP Camera • (1) Quick Start Guide • (1) WPS-ACC-PWR-M Power Adapter • (1) Mounting Base Assembly NOTE: A POWER SUPPLY IS NOT INCLUDED WITH THIS CAMERA. The PS-12DC-1A, WPS-PS multiple output power supply or a Power over Ethernet (PoE) switch is recommended.

  • Page 9: How It Works

    (NVRs) on the same network, or even off the network (with the correct setup and web access). Users can see the camera feed through the interface of their choice, or see recorded footage from a storage device like an NVR. Wirepath Surveillance offers apps for iOS ®...

  • Page 10: Device Layout

    WPS-300-CUB-IP Installation Manual 5.1. Device Layout IR LEDs — Infrared LEDs illuminate nighttime scenes. Fine Focus Adjustment Ring — Turn the ring up to one revolution to make fine focus adjustments for the clearest image. Built-in Microphone — Picks up audio near the camera and streams it with video.

  • Page 11: Assembling And Mounting Your Camera

    WPS-300-CUB-IP Installation Manual 6. Assembling and Mounting Your Camera WARNING: This product is NOT weatherproof. Mount indoors only. The mounting bracket included with the camera is designed for use on any flat surface. Refer to the drawings to determine the best way to assemble the mount and attach it for your application.

  • Page 12: Connecting Your Camera

    Terminate both ends of the cable to 568B. (See pinout above) C. Connect the cable to the camera and the port. 7.1.4. Power for Non-PoE Applications For applications where PoE power will not be used, power the WPS-300-CUB-IP using a standard 12V DC power supply (minimum .5A). Setup Instructions D.

  • Page 13: Audio Out Connection

    WPS-300-CUB-IP Installation Manual 7.2. Audio Out Connection (If audio will be used) Connect the audio out line to an amplifier for playback of camera audio or to a recording device or NVR for audio backup. Pinout S (Sleeve) Common (-)

  • Page 14: Network Software Setup - Ip Installer

    WPS-300-CUB-IP Installation Manual 7.4. Network Software Setup - IP Installer The IP Installer software included with the camera provides a quick view of Wirepath™ IP Surveillance devices connected to the local network. Use the Installer to search for and set basic IP settings for each camera.

  • Page 15: Ip Installer-Configuring Camera Ip Settings

    WPS-300-CUB-IP Installation Manual 7.5. IP Installer-Configuring Camera IP Settings By default, the camera will receive a DHCP IP address. This should be changed to a reserved or static IP address so that the camera remains accessible after setup. Obtain the settings below from the network administrator before installation.

  • Page 16: Ip Camera Web Interface - Setup And Use

    WPS-300-CUB-IP Installation Manual 8. IP Camera Web Interface - Setup and Use 8.1. First Time Access Instructions Connect the PC to the same local network (LAN) the camera is connected to. Open the web browser and enter the IP address that was assigned to the camera. The address should include the port number assigned to the camera if one was set.

  • Page 17: Camera Web Browser Interface

    WPS-300-CUB-IP Installation Manual 8.2. Camera Web Browser Interface The web browser Home screen displays video and current information from the camera feed. The camera name, time signature, video frame size and frames per second (FPS) being streamed are all displayed by default. Use the drop-down menus and buttons to interact with the cameras inputs and outputs, change the stream, or enter the setup menus.

  • Page 18: Web Interface Layout - Bottom Bar

    WPS-300-CUB-IP Installation Manual 8.2.2. Web Interface Layout - Bottom Bar Information Bar Displays basic information about the camera feed. Video Size Adjusts the size of the Live View area within the browser window. Video Source (If Streaming 2 is enabled) Allows for selection of one of two video streams from the camera.

  • Page 19: Camera Configuration Menu Setup

    WPS-300-CUB-IP Installation Manual 9. Camera Configuration Menu Setup After browser access to the camera has been established, the remaining steps for setup may be completed so that cameras are remotely viewable (from inside and outside of the LAN) but secure from unwanted access.

  • Page 20: System Information And Settings

    WPS-300-CUB-IP Installation Manual 9.2. System Information and Settings 9.2.1. System Information Menu Settings • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner. 9.2.1.1. Server Information MAC Address Cannot be changed. Use the MAC address to identify a camera if IP settings have been lost.

  • Page 21: Time Setting

    WPS-300-CUB-IP Installation Manual 9.2.1.3. Time Setting Server Time Current time based on the settings saved in the camera. Date Format Select the order in which days (d), months (m), and years (y) are displayed. (Only available for NTP and Manual mode) Set the camera time zone in hours ahead of or behind Time Zone Greenwich Mean Time (GMT).

  • Page 22: Camera Time Setup

    WPS-300-CUB-IP Installation Manual 9.2.2. Camera Time Setup Important! Wirepath™ Surveillance strongly recommends using the “NTP” time setting option unless Internet access is not available from the camera network. Other settings may not keep the correct time after power outages or other failures.

  • Page 23: Ntp Setup Instructions (For Cameras With Internet Access)

    WPS-300-CUB-IP Installation Manual 9.2.2.5. NTP Setup Instructions (For Cameras with Internet Access) Set the Time Setting option to “NTP”. Set the desired Date Format and Time Zone. C. If applicable to your region, check the box to enable Daylight Savings Settings: •...

  • Page 24: User Management

    WPS-300-CUB-IP Installation Manual 9.2.3. User Management • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner, then click “User Management” in left column “System” sub-menu. 9.2.3.1. Anonymous User Login Enabling this feature allows anyone that visits the address of the camera to: •...

  • Page 25: Administrator Account Setup

    WPS-300-CUB-IP Installation Manual 9.2.3.5. Administrator Account Setup Once the camera is accessible on the network, the administrator password should be changed to prevent unwanted access. Select a new password up to ten characters in length made up of letters and numbers (no punctuation or symbols).

  • Page 26: System Update

    WPS-300-CUB-IP Installation Manual 9.2.4. System Update • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner, then click “User Management” in left column “System” sub-menu. Important! Updating Firmware MUST be performed over a wired IP connection to the device to ensure that a connection is sustained throughout the process.

  • Page 27: How To Back Up Camera Settings

    WPS-300-CUB-IP Installation Manual 9.2.4.4. How To Back Up Camera Settings Once the settings for a camera have been set up, they can be downloaded to a configuration backup file in case the camera is reset or must be replaced later. This file saves ALL settings from the configuration menus that can be modified.

  • Page 28: Upgrade The Firmware

    WPS-300-CUB-IP Installation Manual 9.2.4.6. Upgrade the Firmware Important! Updating Firmware MUST be performed over a wired IP connection to the device to ensure that a connection is sustained throughout the process. If connection is lost during update, use the IP Installer to find the device again and re-start the update.

  • Page 29: Network Ip Settings

    WPS-300-CUB-IP Installation Manual 9.3. Network IP Settings • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner, then click “IP Settings” in left column. 9.3.1. Basic IP Settings 9.3.1.1. IP Assignment Important! These settings are required for the camera to communicate correctly at all times. Use only static IP addresses.

  • Page 30: Port Assignment

    WPS-300-CUB-IP Installation Manual Basic IP Settings, Continued 9.3.1.2. Port Assignment Port for accessing the camera web interface. Set to 80 by default. Each Camera must have a unique Web Page port number in order to access from outside the local network. To make port numbering easy to Port remember, use 4 digits: “8”...

  • Page 31: Rtsp Setting

    WPS-300-CUB-IP Installation Manual Basic IP Settings, Continued 9.3.1.4. RTSP Setting The camera supports Real Time Streaming Protocol (RTSP). RTSP is a network protocol designed to allow media devices to stream content over Ethernet to devices on the same network or even to devices over the Internet. Instead of using a separate server or video recorder to control the video feed to remote devices, RTSP allows direct control of the stream from within the camera.

  • Page 32: Onvif

    WPS-300-CUB-IP Installation Manual Basic IP Settings, Continued 9.3.1.6. ONVIF The ONVIF (Open Network Video Interface Forum) standard is used by IP surveillance for communication across devices from various manufacturers. This setting does not require configuration when being used with Wirepath™ IP surveillance devices ONVIF Select the desired ONVIF standard to be used in the camera, or disable the feature.

  • Page 33: Advanced Ip Settings - Https Access Setup

    WPS-300-CUB-IP Installation Manual 9.3.2. Advanced IP Settings - HTTPS Access Setup Accessing the Camera through HTTPS provides an additional security level for the video stream by requiring certificate authentication. To use this feature, a certificate must be created and then verified by a third party. To set up HTTPS access correctly, contact the HTTPS verifier.

  • Page 34: Advanced Ip Settings - Snmp

    WPS-300-CUB-IP Installation Manual 9.3.3. Advanced IP Settings - SNMP SNMP (Simple Network Management Protocol) is used for network management of larger networks. It allows for monitoring network devices such as IP cameras via a management host. This is an advanced setting that should be used only on larger systems.

  • Page 35: Advanced Ip Settings - Access List (Ip Filter)

    WPS-300-CUB-IP Installation Manual 9.3.4. Advanced IP Settings - Access List (IP Filter) IP address filtering is used to allow or deny access to the camera from individual IP addresses or ranges of IP addresses. This adds an additional layer of security to the camera.

  • Page 36: Add Or Remove Ip Addresses Or Ranges

    WPS-300-CUB-IP Installation Manual 9.3.4.2. Add or Remove IP Addresses or Ranges Enable IP Address Filtering to gain access to the settings: Enter an IP address or range of addresses into the field and select whether to allow or deny access:...

  • Page 37: Advanced Ip Settings - Qos/Dscp

    WPS-300-CUB-IP Installation Manual 9.3.5. Advanced IP Settings - QoS/DSCP Quality of Service (QoS) is used within a network to define priority levels for selected traffic. This allows for a higher level of bandwidth to be used whenever a particular type of traffic is being sent to avoid latency and packet loss. The network administrator should be consulted before enabling this feature.

  • Page 38: Pppoe Setup

    WPS-300-CUB-IP Installation Manual 9.3.6. PPPoE Setup 9.3.6.1. PPPoE Overview Point-to-Point Protocol Over Ethernet (PPPoE) is a network protocol primarily used with DSL (Digital Subscriber Line) providers and modems. This protocol requires a login to connect to the modem even when a router is used. Configuration of these settings is not required to operate the camera on a standard network.

  • Page 39: Ddns Setup

    WPS-300-CUB-IP Installation Manual 9.3.7. DDNS Setup 9.3.7.1. DDNS Overview Dynamic Domain Name Servers (DDNS) map an alphanumeric Internet domain name to a network’s WAN IP address. When configured, DDNS enables login to cameras from anywhere on the Internet without having to remember a numeric address – that could change on a regular basis.

  • Page 40: Setting Up A Ddns Address - Wirepathdns

    WPS-300-CUB-IP Installation Manual 9.3.7.4. Setting Up a DDNS Address – WirepathDNS To use Wirepath DDNS service, enable the DDNS feature by selecting the button. Enter a prefix for the address in the host name field as shown in the example above (system1).

  • Page 41: Server Settings

    WPS-300-CUB-IP Installation Manual 9.3.8. Server Settings Server Settings menus allow configuration of the message and file transfer systems used by the camera to send emails, video files, or snapshots to: email recipients, to an FTP server, or to be hosted over the local network.

  • Page 42: Ftp Settings

    WPS-300-CUB-IP Installation Manual 9.3.8.3. FTP Settings An FTP server is a remote computer server the camera connects to over the network or Internet. When an FTP server is configured, recorded video and snapshot files can be stored on the server for later access. Contact the network administrator for FTP server setup information.

  • Page 43: Network Share Settings

    WPS-300-CUB-IP Installation Manual 9.3.8.4. Network Share Settings • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner, then click “Server Settings” in left column menu. In the Server Settings sub-menu on the main window of the page, click “Network Share Settings”.

  • Page 44: Camera A/V Settings

    WPS-300-CUB-IP Installation Manual 9.4. Camera A/V Settings 9.4.1. Image Settings Menu The image setting menu is used to set up the camera view for the best image possible. Brief descriptions of the menu are given below. Complete instructions for setup are in the following sections.

  • Page 45: Tips For Getting The Best Camera Image

    WPS-300-CUB-IP Installation Manual 9.4.1.1. Tips for Getting the Best Camera Image • Too much brightness causes the image to fade. Too little brightness will cause dark colors to run together. • Too much contrast will cause obscured details. Too little contrast will cause the image to lose clarity and brightness.

  • Page 46: How To Configure Day And Night Settings (Color Modes)

    WPS-300-CUB-IP Installation Manual 9.4.2. How to Configure Day and Night Settings (Color Modes) The camera can record an image in color or black-and-white mode. Color mode requires more light but provides the best image given ideal conditions. Black and white requires much less light, and the camera’s IR can be turned on to illuminate the scene.

  • Page 47: Light Sensor Mode (Default Mode)

    WPS-300-CUB-IP Installation Manual 9.4.2.2. Light Sensor Mode (Default Mode) The default day-night settings are usually ideal. The camera has been calibrated to run in color mode as long as enough ambient light is available for the sensor to use. Once the scene begins to darken, the camera will adjust to black and white night mode, and the IR LEDs will turn on as needed.

  • Page 48: How To Configure Privacy Masks

    WPS-300-CUB-IP Installation Manual 9.4.2.4. How To Configure Privacy Masks Privacy mask allows for areas of an image to be blocked out to avoid unwanted capturing of sensitive areas. Example: A camera used to monitor the front lawn of a house would have the windows on the neighboring homes masked to avoid peeping on the neighbors.

  • Page 49: Video Settings Menu Overview

    WPS-300-CUB-IP Installation Manual 9.4.3. Video Settings Menu Overview The Camera supports up to four streams that can be used for streaming to a mobile device, network recorder, control system GUI, or the browser GUI simultaneously. While the highest quality is desired, it may not be supported by the network or device.

  • Page 50: Video Streaming 1 And 2 Setup

    WPS-300-CUB-IP Installation Manual 9.4.4. Video Streaming 1 and 2 Setup Note: Streaming 1 and 2 settings are identical. Settings options have only been covered once. Basic/ Set the streaming mode to “Advanced” to allow fine control of streaming parameters. Extra options for Advanced Advanced mode are indicated below.
  • Page 51 WPS-300-CUB-IP Installation Manual Video Streaming 1 and 2 Setup, Continued GOP (Group of Pictures) is used to generate the visible frames of a video stream. The GOP size setting determines the multiplier to use for producing intermediate frames based on a standard of 15fps.

  • Page 52: Streaming 3 And 4 Setup

    WPS-300-CUB-IP Installation Manual 9.4.5. Streaming 3 and 4 Setup 9.4.5.1. Streaming 3 Video Quality Changes the video bitrate based on a level from Low (slowest) to Best (fastest). Click “Apply” at the bottom-right of the page to save modified settings.

  • Page 53: Event Record Setup And Scheduling

    WPS-300-CUB-IP Installation Manual 9.5. Event Record Setup and Scheduling Cameras can be set up to record on a set schedule, or in response to contact closure, motion or tampering. Set up how and when events are handled, including if and when to send an email notification or to send a file backup of an event to an off-site location.

  • Page 54: Record File

    WPS-300-CUB-IP Installation Manual 9.5.1.1. Record File Selects the file type to create when the event occurs: • AVI File – Creates a short .AVI format video file. • JPEG Files (Streaming 1 must be set MJPEG) – Creates a series of JPEG files at about 1 FPS.

  • Page 55: Pir Setting (Passive Infrared Sensor)

    PIR Setting (Passive Infrared Sensor) The WPS-300-CUB-IP is equipped with an external Passive Infrared Sensor (PIR) to sense motion in addition to the standard in- camera motion detection. Use this sensor to detect people and animals passing through the field of view. The sensor works within the following areas: 10.2 ft.

  • Page 56: Configuring Motion Detection Areas

    WPS-300-CUB-IP Installation Manual 9.5.2. Configuring Motion Detection Areas Motion detection allows for specific areas of the image to be used for triggering the recording of video, an alarm, or sending a notification. When an area is defined, motion in that area will trigger the predefined action; this is useful to avoid unwanted events from being triggered due to motion in areas of no concern.

  • Page 57: Adding A New Motion Detection Area

    WPS-300-CUB-IP Installation Manual 9.5.2.2. Adding a New Motion Detection Area Select Event Setting under Event on the left side Menu. Select the Area for Motion Detection. C. Select Area 1 next to the blue box. D. Place the mouse at the upper left hand corner of the area to mask, hold down the left mouse button and drag the box over the area to mask and release the mouse button.

  • Page 58: Schedule Menu

    WPS-300-CUB-IP Installation Manual 9.5.3. Schedule Menu Use this menu to configure a schedule for capturing images from the camera to be stored. Enable Check box to Enable Scheduling feature. Grid with Days of the Week and Time of day for snapshots to be recorded. Enabled dates and time appear as a Green box.

  • Page 59: How To Set Up Scheduling For Events

    WPS-300-CUB-IP Installation Manual 9.5.3.2. How to Set Up Scheduling for Events Select Schedule under Event on the left side Menu. Select the Enabled check box. C. Click on the box(es) to enable one-hour blocks of time for the desired Day of week and Time of day.

  • Page 60: Log List

    WPS-300-CUB-IP Installation Manual 9.6. Log List The camera software stores a log file for several parameters in the camera. Use the Log List menu to select a log to view. 9.6.3.1. System Log Displays System events such as logins and configuration changes. This log is maintained even through loss of power.

  • Page 61: Sd Card Menu

    WPS-300-CUB-IP Installation Manual 9.7. SD Card Menu Use this menu to set up and access a microSD card. 9.7.1. Playback This area will display “No SD Card” when no microSD card is installed. When a compatible card is installed and the card contains media, folder names are displayed using the dates when media was saved as titles.

  • Page 62: Mobile App Access

    WPS-300-CUB-IP Installation Manual 10. Mobile App Access FREE Use your computer, or iPhone ® , native iPad ® , or Android ® smartphone apps to view cameras while at the office or on the go. Details on setup and operation can be found at www.SnapAV.com.

  • Page 63: Manual Camera Reset

    WPS-300-CUB-IP Installation Manual 11. Manual Camera Reset If the camera ever becomes unresponsive after an update, or Administrator access is lost, it may be necessary to manually reset the camera back to default configuration. The procedure was designed to require significant effort so that resets could not easily be done with malicious intent.

  • Page 64: Specifications

    WPS-300-CUB-IP Installation Manual 12. Specifications Imaging Image sensor 1/2.7” 2MP CMOS sensor Lens Type 2.8mm Fixed Lens F2.0 0.1 lux @F2.0 (IR off) Minimum Illumination 0 lux @F2.0 (IR on) Shutter Speed 1/5~1/1000 True Day/ Night (IR Cut Filter) Built-in 4 IR LED IR Distance —...
  • Page 65 WPS-300-CUB-IP Installation Manual Compression format H.264/ M-JPEG Video bitrates Constant (CBR), and Variable (VBR) Motion Detection Yes, 3 different areas Tampering Email Actions upon Triggers Save to micro SD card Digital Output SAMBA Pre/ Post alarm Yes, configurable Security and QoS...

  • Page 66: Warranty

    WPS-300-CUB-IP Installation Manual 13. Warranty 3-Year Limited Warranty This Camera has a 3-Year Limited Warranty. The warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products that have been abused, modified, disassembled, or improperly installed.
  • Page 67 © 2014 Wirepath™ Surveillance 140703-1408...
