WPS-565-DOM-A
DOME
CAMERA
INSTALLATION MANUAL
Review manual thoroughly before installation.
Retain for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPS-565-DOM-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wirepath Surveillance WPS-565-DOM-A

Summary of Contents for Wirepath Surveillance WPS-565-DOM-A

  • Page 1 WPS-565-DOM-A DOME CAMERA INSTALLATION MANUAL Review manual thoroughly before installation. Retain for future reference.

  • Page 2: Safety Instructions

    WPS-565-DOM-A Installation Manual Safety Instructions This information is provided to ensure your safety and to prevent physical or fi nancial loss. Please read this document carefully before installing and operating the camera. 1. Handle with care. Use caution when handling to avoid damage to sensitive internal components.

  • Page 3: Table Of Contents

    WPS-565-DOM-A Installation Manual Table of Contents 1. Features 2. Package Contents 3. Wiring Recommendations 3.1. Wiring Connections 4. Installation Instructions 5. Camera Operation Setup 5.1. Focus, Zoom and Position 5.2. Using the Test Adapter 6. OSD SETUP Menu 6.1. Default Settings Description 6.2.
  • Page 4 WPS-565-DOM-A Installation Manual 6.4.6. DPC (Dead Pixel Compensation) 6.4.7. SPECIAL Menus 6.4.7.1. CAM TITLE Setting 6.4.7.2. MOTION Detection 6.4.7.3. PRIVACY Setting 6.4.7.4. PARK LINE Setting 6.4.7.5. IMAGE ADJ. Setting 6.4.7.6. COMM ADJ. — RS485 Setup 6.4.8. Exit Menu — Save and Reset 6.4.8.1.

  • Page 5: Features

    WPS-565-DOM-A Installation Manual 1. Features 1/3” 960H Sony Super-HAD II CCD The Sony Super HAD II CCD is ideal for low lux illumination, resulting in a clear and crisp image. Varifocal Auto-Iris Lens This camera features a varifocal lens with a focal length of 2.8-12 mm. The auto- iris function intuitively manages the amount of light passing through the lens for consistent image brightness.

  • Page 6: Package Contents

    WPS-565-DOM-A Installation Manual 2. Package Contents (1) WPS-565-DOM-A Camera (1) WPS-ACC-PWR-M AC/DC Power Plug (1) OSD Joystick / BNC Test Adapter (4) Surface Mounting Screws (includes 1 spare) (4) Wall Anchors (includes 1 spare) (1) 3mm Allen key (1) Foam gasket...

  • Page 7: Wiring Recommendations

    WPS-565-DOM-A Installation Manual 3. Wiring Recommendations Wiring should be installed, terminated, and tested for connectivity before the camera is installed. Specifications for each connection are detailed below. 3.1. Wiring Connections 12V DC RS485 Leads Power In Video Out 1. Power (Required) It is recommended to install the camera power supply near the recording location and run a remote power wire to the camera.

  • Page 8: Installation Instructions

    WPS-565-DOM-A Installation Manual 4. Installation Instructions Wiring must be installed before the camera. See the previous page for connections and wiring recommendations. Step 1. Prepare for Installation Important! DO NOT remove the protective plastic film from the camera dome until installation is complete and the camera is being sealed for the last time.
  • Page 9 WPS-565-DOM-A Installation Manual Step 2. Mount the Camera Using Mounting Accessories Mount the accessory according to its instructions, make wiring connections, and mount the camera. Then, continue these instructions below at Step 3 to complete camera installation. Surface Mounting A. Use the included template to mark the screw loca- tions for mounting.

  • Page 10: Camera Operation Setup

    WPS-565-DOM-A Installation Manual 5. Camera Operation Setup 5.1. Focus, Zoom and Position The lens of the camera has manual focus and zooms knobs for setting the correct field of view and the gimbal may be rotated for tilt correction. Connect the test adapter as described below to use a monitor at the camera location for viewing adjustments.

  • Page 11: Osd Setup Menu

    WPS-565-DOM-A Installation Manual 6. OSD SETUP Menu WPS-565 series cameras use an on-screen (OSD) menu system for setup of advanced image and control settings. SETUP LENS EXPOSURE WHITE BAL BACKLIGHT DAY&NIGHT SPECIAL EXIT SAVE Default OSD menu view and settings Use the OSD SETUP menu to: •...

  • Page 12: How To Navigate The Osd Setup Menu

    WPS-565-DOM-A Installation Manual 6.2. How to Navigate the OSD SETUP Menu The OSD menu is displayed as an overlay of the camera field-of-view. It will remain visible as long as the menu is active. Use the test adapter or RS485 to navigate.

  • Page 13: Osd Menu Structure Outline

    WPS-565-DOM-A Installation Manual 6.3. OSD Menu Structure Outline BRIGHTNESS 0...42...255 LENS IRIS SPEED 0...4...15 MANUAL BRIGHTNESS 0...37...255 AUTO 1/60 FLK(1/120) 1/250 1/500 1/1000 1/2000 1/4000 1/5000 1/10000 1/100000 SHUTTER BRIGHTNESS 0...37...255 MIDDLE EXPOSURE HIGH LEVEL 0...35...63 DWDR AWC->SET ANTI. CRL WHITE BAL.
  • Page 14 WPS-565-DOM-A Installation Manual CAM TITLE (all 4 are on by default) AREA SEL. AREA STATE HEIGHT 0...3...15 MOTION WIDTH 0...3...15 LEFT/RIGHT 0...2...15 TOP/BOTTOM 0...2...15 DEGREE 0...32...255 VIEW (all 8 are on by default) AREA SELECT AREA STATE HEIGHT 0...255 (default setting varies for each of the 8 areas)

  • Page 15: Osd Menu Settings

    WPS-565-DOM-A Installation Manual 6.4. OSD MENU SETTINGS 6.4.1. LENS Menu The amount of light entering the camera lens is controlled by the size of the aperture, (called IRIS in SETUP menu). SETUP LENS • The default DC setting is recommended when lighting levels vary regularly.

  • Page 16: Exposure Menu

    WPS-565-DOM-A Installation Manual 6.4.2. EXPOSURE Menu Exposure settings use the sensor in the camera to control how much light is recorded in each frame of video. EXPOSURE SHUTTER AUTO MIDDLE DWDR RETURN • Access the EXPOSURE sub-menu settings from the main SETUP menu.

  • Page 17: White Balance Menu

    WPS-565-DOM-A Installation Manual 6.4.3. WHITE BALANCE Menu White balance adjusts the image color according to the lighting conditions of the scene to correct for different lighting color ranges. SETUP WHITE BAL • Move the joystick left or right to select the desired mode.

  • Page 18: Backlight Menu

    WPS-565-DOM-A Installation Manual 6.4.4. BACKLIGHT Menu Back Light Compensation (BLC, default) clarifies objects in front of bright light. For example, in a scene with lighting facing the camera, if a person walks toward a normal camera, they will appear as a silhouette, but BLC will adjust contrast for more detail.

  • Page 19: Day & Night Menu

    WPS-565-DOM-A Installation Manual 6.4.5. DAY & NIGHT Menu The camera sensor has DAY (color) and NIGHT(black and white) mode. Use this menu to set up the mode, how it is switched and also IR levels. • Move the joystick left or right to select a mode and enter its sub-menu (if applicable).

  • Page 20: Dpc (Dead Pixel Compensation)

    WPS-565-DOM-A Installation Manual 6.4.6. DPC (Dead Pixel Compensation) Dead Pixel Compensation automatically removes defective pixels and “fills in” the image. Use the UP arrow function to exit this menu without performing DPC. DPC VIEW LS VALUE | | | | | | | | | | | | | | | DIFF.

  • Page 21: Special Menus

    WPS-565-DOM-A Installation Manual 6.4.7. SPECIAL Menus 6.4.7.1. CAM TITLE Setting The CAM TITLE sub-menu provides the ability to set a camera name and have it appear on the screen. • CAM TITLE — Set to ON to display the camera name on the screen.

  • Page 22: Privacy Setting

    WPS-565-DOM-A Installation Manual 6.4.7.3. PRIVACY Setting Privacy Mask allows the masking of up to 8 “surveillance-free” zones in the field of view. This may be used for a camera that has a neighbor’s window in part of the scene, or with an area where sensitive information would be visible.

  • Page 23: Image Adj. Setting

    WPS-565-DOM-A Installation Manual 6.4.7.5. IMAGE ADJ. Setting IMAGE ADJUST LENS SHAD. 2DDNR MIRROR FONTCOLOR CONTRAST | | | | | | | | | | | | | | | SHARPNESS | | | | | | | | | | |...

  • Page 24: Comm Adj. - Rs485 Setup

    WPS-565-DOM-A Installation Manual 6.4.7.6. COMM ADJ. — RS485 Setup Set up remote control of the camera’s OSD SETUP menu from a PTZ controller or DVR through RS485. COMM ADJ CAMERA ID BAUDRATE 4800 PROTOCOL PELCO-D DISPLAY ID ID POS RETURN •...

  • Page 25: Troubleshooting

    WPS-565-DOM-A Installation Manual 7. Troubleshooting If you have trouble operating the camera, first refer to the following guidelines. If the problem persists, contact Technical Support at (866) 838-5052. Nothing appears on the display: • Check if the power for the camera and the monitor is ON.

  • Page 26: Specifications

    WPS-565-DOM-A Installation Manual 8. Specifications Imaging Image Sensor 960H 1/3" Color Sony Super HAD II Lens 2.8 ~ 12mm Auto Iris Vari-Focal Lens Estimated Horizontal Viewing Angle 92˚(W)~30˚(T) Resolution (TVLs) Effective Pixels NTSC:976(H)x494(V) Gamma 0.45 S/N Ratio >50dB Sync. Mode...

  • Page 27: Dimensions

    WPS-565-DOM-A Installation Manual 9. Dimensions 5.91" Maximum Camera Angle 4.04" Side View 67.0° 67.0° Top View 10. 5-Year Limited Warranty This camera has a 5-Year Limited Warranty. The warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use.
  • Page 28 140422-1720 © 2014 Wirepath Surveillance...
