- Page 1 WPS-350-BUL-A-GR WPS-350-BUL-A-WH BULLET CAMERA INSTALLATION MANUAL Review manual thoroughly before installation. Retain for future reference.
-
Page 2: Table Of Contents
WPS-350-BUL-A Installation Manual CONTENTS Safety Instructions ..................3 Features.......................4 Package Contents ..................4 Installation Instructions ................7 Troubleshooting ..................10 Dimensions ....................12... -
Page 3: Safety Instructions
5. Do not install the camera in environments with extreme humidity. Installing camera in environments with extreme humidity may cause moisture to condense on the surface of the lens or dome cover, which can affect picture quality. © 2013 Wirepath Surveillance... -
Page 4: Features
WPS-350-BUL-A Installation Manual FEATURES • 1/3” Sony Super-HAD II CCD The Sony Super HAD II CCD is ideal for low lux illumination, resulting in a clear and crisp image. • Varifocal Auto-Iris Lens This camera features a varifocal lens with a focal length of 4-9mm. The auto- iris function intuitively manages the amount of light passing through the lens for consistent image brightness.. - Page 5 WPS-350-BUL-A Installation Manual OPTIONAL ACCESSORIES Wirepath Surveillance offers a wide range of accessories that provide power to the cameras, allow for various mounting options, and make connection to the head end quick and easy. MOUNTS • WPS-MNT-FLUSH-BUL Use when the camera needs to be attached to a flush mount junction box.
- Page 6 WPS-350-BUL-A Installation Manual WIRING ACCESSORIES In addition to mounts and power supplies, Wirepath offers a full line of accessories to easily send power, audio, and video over 2 conductors of Cat5 wiring back to the head end. Visit www.snapav.com for a complete listing of accessories. •...
-
Page 7: Installation Instructions
12 volt DC power supply will damage the camera. The power supply used must be rated to 1 amp per output minimum. DC Plug 12V DC Power BNC Video © 2013 Wirepath Surveillance Output... - Page 8 WPS-350-BUL-A Installation Manual 3. Mount the Camera A. Mounting directly to a wall or eve: A.1 - Use the Camera base as a template to mark the screw locations. A.2 - Predrill holes in the marked locations. A.3 - Connect the wires from the wall to the Cameras Pigtail and insert them into wall.
- Page 9 F. Adjust the Cameras Focus (furthest from the lens) using the supplied 3mm Allen key. G. Once the Zoom and Focus are adjusted, disconnect the BNC Test Adapter and replace the plate removed in step 4-A. © 2013 Wirepath Surveillance...
-
Page 10: Troubleshooting
WPS-350-BUL-A Installation Manual TROUBLESHOOTING If you have trouble operating the camera, first refer to the following guidelines. If the problem persists, contact Technical Support at 866.838.5052. Nothing appears on the display • Check if the power for camera and monitor is ON. •... -
Page 11: Specifications
14°F - 140°F Operating Humidity 30% - 80% RH Power Source 12 VDC (500 mA) Power Consumption 3.5W- 290mA Dimensions 8.39” (L) x 3.82” (H) with sun shade and bracket fully extended Weight 1.70 lb. (770g) © 2013 Wirepath Surveillance... -
Page 12: Dimensions
WPS-350-BUL-A Installation Manual DIMENSIONS 9.07in. 8.39in. 3.24in. 3.73in. 0.6in. Ø 3.06in. - Page 13 Products to be repaired under this warranty must be returned to Wirepath™ Surveillance or a designated service center with prior notification and an assigned return authorization number (RA). CONTACTING TECHNICAL SUPPORT Phone: (866) 838-5052 Email: Techsupport@snapav.com © 2013 Wirepath Surveillance...
- Page 14 130221-1445 © 2013 Wirepath Surveillance...
