Removing the Hard Disk from the Lower HDD Bay Slot
1. Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat-
tery and any HDD in the upper slot.
2. Remove screws &
1
3. Raise the HDD assembly up at an angle
4. Remove the HDD assembly
1
2
3
.
2
as illustrated.
3
from the bay
.
4
Upgrading The Computer
4
Upgrading the Hard Disk Drive(s) 6 - 13
Figure 6 - 9
Lower Slot Hard
Disk Assembly
Removal
