External Locator - Front & Right Side Views - EUROCOM P570WM Service Manual

External Locator - Front & Right side Views
2
3
1 3
2
4 5 5
1
6
7
External Locator - Front & Right side Views 1 - 5
Introduction
Figure 2
Front Views
1. LED Power
Indicators
2. Express Card Slot
3. Multi-In-1 Card
Reader
Figure 3
Right Side Views
1. Line-In Jack
2. S/PDIF-Out Jack
3. Microphone-In Jack
4. Headphone-Out
Jack
5. 2 * USB 2.0 Ports
6. Sub Woofer
7. Security Lock Slot
