Interface
Three USB 3.0 Ports (Including one AC/DC Pow-
ered USB/eSATA port)
Two USB 2.0 Ports
One eSATA Port (USB 3.0 Port Combined)
One HDMI-Out Port
One DVI-Out Port
One S/PDIF Out Jack
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One Line-In Jack
One Mini-IEEE1394b Port
One RJ-45 LAN Jack
One DC-In Jack
One DisplayPort
Note: External 7.1CH Audio Output Supported
by Headphone, Microphone, Line-In and S/PDIF
Out Jacks
Environmental Spec
Temperature
° °
Operating: 10 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 16.9A (330W)
DC Output: 20V, 15A (300W)
Removable Polymer Smart Li-Ion 78.44WH Bat-
tery Pack
(Factory Option) Power Converter Box
Dimensions & Weight
419mm (w) * 286mm (d) * 57.9mm - 62.1mm (h)
Around 5.5kg with 1 Video Card, Battery and
ODD
