External Locator - Front & Right side Views
1 2 3 4 5 6
1 2
7 8 9
External Locator - Front & Right side Views 1 - 5
Introduction
Figure 2
Front Views
1. Consumer
Infrared
Transceiver (for
Optional TV
Tuner)
2. LED Power
Indicators
Figure 3
Right Side Views
1. Headphone-Out
Jack
2. Microphone-In
Jack
3. Line-In Jack
4. S/PDIF-Out Jack
5. USB 3.0
6. ExpressCard Slot
7. e-SATA Port
8. DVI-Out Port
9. Security
(Kensington) Lock
Slot
