External Locator - Front & Right Side Views - EUROCOM W860CU Service Manual

External Locator - Front & Right side Views
1
1 2
W860CU
W870CU
W860CU
2 3 4
6
5
W870CU
3 4
6
5
1
2 1
10
7
8
9
7
8
External Locator - Front & Right side Views 1 - 5
Introduction
Figure 2
Front Views
1. LED Power
Indicators
2. Consumer
Infrared
Transceiver (for
Optional TV
Tuner)
Figure 3
Right Side Views
1. Headphone-Out
Jack
2. Microphone-In
Jack
3. Line-In Jack
4. S/PDIF-Out Jack
5. USB 2.0 Port
6. ExpressCard Slot
7. e-SATA Port
8. DVI-Out Port
9. Security
(Kensington) Lock
Slot (W870CU
Only)
10. Power Button
(W860CU Only)
