Zaxcom Fusion User's Manual_____________________________________________________Chapter 11

Know Firmware Issues

NOTE: Turn „OFF‟ all effects before switching to a higher sampling-rate. If you want to use 192 kHz mode, then
you should perform a factory restore defaults to insure all effects are turned „OFF‟.
When changing from 192 kHz to 48 kHz sample-rate, select 96 kHz first as an intermediate step to prevent a
possible freeze. Holding the 0 key while booting will force the Fusion back into 48 kHz mode.
NOTE: Mirror Disk Playback must not be enabled while mirror mode is on. Doing so will cause the unit to
appear to be in playback when it is not. The Play key may not update properly until the current page is
exited.
NOTE: Playback from a DVD-RAM disk or FireWire drive often will not be fast enough to sustain the Fusion‟s
playback buffer. This will often result in only partial playback of a file. Press the STOP key periodically to
allow the playback buffer to fill back up.
WARNING: If you install software versions lower than z3.55 onto a Fusion, the internal DVD drive and CF card
slot will not function. This may make it difficult to install a newer version.
NOTE: As of V4.00, you must select the folder to mirror. Fusion will no longer assume that you want to mirror
the current RECORD folder. You may also change the RECORD folder without affecting the currently
mirroring folder.

Firmware History

===================================================================================================================
V7.09 2010-03-16
Ver # Ver Date
Fixed problem with Mix-8 / Mix-12 fader movement slowing down recording process
Changed expanded output routing to allow routing copies of outputs (to reduce duplicated crosspoints)
===================================================================================================================
V7.08 2009-12-16 ZAXNET BETA VERSION
Ver # Ver Date
Changed Moved ZaxNet button to the left to avoid changes during touch screen malfunction
===================================================================================================================
V7.05 UNKNOWN
Ver # Ver Date
Fixed Aux Line input trim 1 – 4 which were not being updated after a power cycle
Changed Allow over-clocked (by 10%) DSP speed (320MHz) when the #2 key is held during boot-up
Fixed Battery screen index
Fixed Meter label entry screen tab bug
Changed Properly update limiter crosspoint display
Fixed decimal point entry in battery meter screen (use backspace key)
===================================================================================================================
V7.03 UNKNOWN
Ver # Ver Date
Fixed Was not properly saving the trim mode on digital inputs.
===================================================================================================================
V6.08K UNKNOWN
Ver # Ver Date
Changed No longer send ZaxNet commands if the Timecode screen is being displayed (for non ZaxNet compatible slates).
===================================================================================================================
V6.08F UNKNOWN
Ver # Ver Date
Added Low battery warning on boot up (9.0 volts).
===================================================================================================================
V6.06C UNKNOWN
Ver # Ver Date
Added F6 (INPUT key on Fusion) boot key: causes a folder recovery operation.
NOTE: the recovered folder info is NOT written to the drive unless a recording is made in that folder!
===================================================================================================================
V6.03U 2009-06-26
Ver # Ver Date
Changed Better free space left on mirror disk indicator on Mirror Drive Status button
===================================================================================================================
V6.02U 2009-06-25
Ver # Ver Date
Changed potential bug in GUI that could cause a crash
Added free space left on mirror disk indicator on Mirror Drive Status button (FAT32 disks only)
163
