Chapter 5______________________________________________________Zaxcom Fusion User's Manual

Load a Factory Preset

To load a factory preset, perform the following:
1. Display the
on the
2. Press the Factory Presets button on the
3. Press the appropriate Preset button on the

Build Your Own Headphone Mix (Working Preset)

On this page, all armed tracks have
through the button.
To build your own headphone mix, perform the following:
Press the button in the left or right headphone output to assign that headphone output channel.
An X is placed in the button.

Invert Phase

If for some reason, you need to invert the phase on a channel (M/S monitoring, etc), use the Phase Invert button
on the appropriate channel(s). The Fusion displays a bar on top of the X, indicating the channel‟s phase is inverted.
IMPORTANT: Invert Phase only inverts the playback phase; it does not affect the recorded audio in any way.

Retaining Your Headphone Mix with a User Preset

In a lot of cases once you have setup monitoring options, you don‟t need to change them that often. But once
changed, the Fusion allows you to restore those settings with the press of a button. When stored, these become
known as User Presets.

Storing the Mix in a User Preset

You can have up to 12 presets. To store a preset, perform the following:
1. Press the User Presets button on the
2. Press the Load/Save Toggle button at the bottom to change the title to "Save User Preset"
3. Press any unassigned Preset button on the
(The
4. Enter the name (maximum 8 characters.) and press the ENTER key.
NOTE: The preset name does not immediately appear on the button. However, the next time you go into the
Load/Save User Presets page
5. Press the MENU key to return to the
(The preset # and the name you entered appear below the page title.)
The User Preset number and the user entered name also appear on the
button.

Loading a Mix Saved in a User Preset

To load a preset, perform the following:
1. Press the Headphone button on the
2. Press the User Presets button. (The
3. Press the Preset button with the preset you want to use. (The LED in the upper left corner turns green.)
4. Press and hold the MENU key until you return to the

Camera Input

To switch between listening to the mix and the camera return, press the F3 key on the keyboard at any time.
NOTE: The Camera Input on the Fusion internally sums the camera mix to mono. This summing occurs only on
the return audio, not audio sent to the camera.
Headphone Mix page
Home page {p.31}, or the Head Phone Mix button on the
Keyboard page {p.123} is displayed to aid in entering the preset button‟s name.)
{p.69} by pressing the HPH key on the front panel, the Headphone button
Headphone Mix page
Factory Presets page
blue numbers and all disarmed tracks have black numbers and a red slash
Headphone Mix page
Load/Save User Presets page
{p.72}, the name will appear on the button.
Headphone Mix page
Home page {p.31}. (The
Load/Save User Presets page
Home page
140
Main Menu page {p.35}.
{p.69}.
{p.71}.
{p.69}.
{p.72}.
{p.69}.
Home page {p.31} in the Headphone
Headphone Mix page
{p.72} is displayed.)
{p.31}.
{p.69} is displayed)
