Chapter 11_____________________________________________________Zaxcom Fusion User's Manual
Significant Change Reminders
Folder Recovery Operation
Boot up while pressing the F6 key (INPUT key). Once the system has settled down, go to the folder that was
recovered and press the REC key, wait 5 seconds and press the STOP key. This causes the recovered data to be
written to the drive.
Saving and restoring Fusion's configuration INI files
Starting in version 5.14 an Export Settings feature was added to allow Users to save and restore all their settings
to or from any (FAT32 formatted) mirror disk.
To save the current configuration settings to a CompactFlash card:
1. Turn Off mirroring and insert a formatted mirror disk or card.
2. Go to the
3. Press the TRIM key then the 5 key. This will copy your configuration memory files to the mirror disk.
To load configuration settings from a CompactFlash card:
1. Turn Off mirroring and insert a mirror disk or card containing the INI files to be loaded.
2. Go to the
3. Press the TRIM key then the 4 key. This will load the INI files into the unit‟s configuration memory.
New Processor speed selection feature
DSP boards labeled REVB in the
processor speed.
Type 036 in the
There is a new Processor Speed button. If the processor speed is set to HIGH, the 192000 button in the
Rate page
kHz recording.
The higher speed will increase the mirroring speed by about 20% and will allow the user to enable more effects
before the screen becomes sluggish.
NOTE: Older Fusions may NOT run reliability at the higher processor speed.
To use the Simultaneous mirror feature:
Go to the
continuous mirror mode. Fusion will mirror the currently selected mirror folder while in record (not during
playback). When mirroring more than 8 tracks at 48 kHz, Fusion may slowly fall behind the mirror process and
may take a few minutes to catch up after the recording stops.
To use the "Mirror All Folders" feature:
Erase your mirror drive (FireWire hard drive) and then select a starting folder in the
{p.116}. Press the Mirroring Mode button to select All Folders. Then go back to the
{p.111} and change the Mirror Mode button to On-NORMAL to start mirroring. The Fusion will mirror
starting at the currently selected mirror folder and will mirror all folders until the end of the disk. Fusion will
over-write any matching segments that are already on the mirror disk.
Main Menu page
{p.35} and type 1967 to open the
Main Menu page
{p.35} and type 1967 to open the
About Fusion page
Main Menu page
{p.35} and go to the
{p.55} should remain enabled. If not, the 9 key must be held during power up in order to allow 192
Mirror Drive page
{p.111} and change the Mirror Mode button to On-CONTIN. to enable the
Debug Screen page
Debug Screen page
{p.122} might not be able to run reliably at the high
Fusion Service Menu page
162
{p.128}.
{p.128}.
{p.127}.
Sample
Mirror Folders page
Mirror Drive page
