Chapter 9______________________________________________________Zaxcom Fusion User's Manual
Bands
Level
Freq Range
Q
Effects (Included)
Disk Limiter (Fusion-10)
Disk Limiter (Fusion-12)
Attack
Decay
Threshold
Ratio
Make-up Gain
Input Highpass Filter
Freq. Range
Input Delay
Time Range
Input Limiter
(parameters fixed)
Output Limiter
Attack
Decay
Threshold
Ratio
Make-up Gain
Recording
Track Count (Fusion-10)
Track Count (Fusion-12)
Bit-depth
Primary
Mirror(s)
Sampling-rates (kHz)
Head Room
Drive Format
Int. Slot -1
Int. Slot -2
Ext. Device
File Formats
Int. Slot 1
Int. Slot 2
Ext. Device
Dual Disk Recording
Max Pre-record (secs)
Timecode Reader/Generator
Timecode Type
Timecode Frame-rates
2
–24.0 to +24.0 dB
30 Hz to 20 kHz
0.5 to 9.9
(x 10)
(x 12)
0.1 to 100.0 ms
10 to 1000 ms
–20.0 to 0.0 dB
4.0:1 to 20.0:1
0.0 to 6.0 dB
(A x 8, D x 8)
Off or 30 to 240 Hz
(A x 8, D x 8)
0 to 60 ms
(A x 8, D x 8)
Yes, No
(x 8)
0.1 to 100.0 ms
10 to 1000 ms
–20.0 to 0.0 dB
4.0:1 to 20.0:1
0.0 to 6.0 dB
10
12
24
16 / 24
44.1, 47.952, 48, 48.048, 88.2, 96, 96.096, 192*
12 to 20 dB
MARF (Mobile Audio Recording Format) II
FAT32
FAT32
.ZAX
BWF-M, BWF-P
BWF-M, BWF-P
Yes
10 seconds (48.048 kHz and below)
* Up to 6 tracks max
SMPTE
23.98, 24, 25, 29.97NDF, 29.97DF, 30NDF, 30DF
