Chapter 2______________________________________________________Zaxcom Fusion User's Manual

Page Notes

None

Page Level Shortcuts

None

Preset Loaded Name field

Appears just below the page title. Indicates which preset (User or Factory) is currently loaded. If it is not a saved
preset, Working Preset is displayed. Default setting: Factory 2

Disk Tracks Matrix buttons

Selects which disk tracks being recorded, are to be monitored. Left (L) and right (R) buttons send the specific
track(s) to the left and/or right ear cups.

Outputs Matrix buttons

Selects which output channels, are to be monitored. Left (L) and right (R) buttons send the specific track(s) to the
left and/or right ear cups.

Camera Returns Matrix buttons

Selects which Camera Returns, are to be monitored. Left (L) and right (R) buttons send the specific track(s) to the
left and/or right ear cups.
NOTE: To monitor a single channel in both the left and right headphone mix, select it in both the left and right sides.

Disk Tracks/Outputs/Camera Returns Toggle button

Cycles the view between Disk Tracks, Outputs and Camera Returns views.

Factory Presets button

Pressing it takes you to the

User Presets button

Pressing it takes you to the

Toggle On Recorded Tracks button

Automatically selects all tracks that are being recorded.

Phase Invert button

Reverses the phase of the monitored channel. This does not change the phase of the recorded channel, it only
reverses phase in the monitor. The selected matrix button will have a line over the X.
NOTE: The phase invert follows any previous phase adjustment done in the recording matrices. If you have
reversed the phase for a channel, you do not have to reverse the phase here. It is already reversed.
Factory Presets page {p.71}.
Load/Save User Presets page
70
{p.72}.
