SBC82810 Pentium M All-in-One Half-Size Board User's Manual
2.3

Jumper Settings

The SBC82810 Series is configured to match the needs of
your application with the proper jumper settings. The table
below is a summary of all the jumpers and their corresponding
functions onboard the SBC82810 Series. The succeeding
tables show the correct jumper settings for the onboard
devices.
Jumper
JP1 Audio Line Out/Speaker Out: Line Out
Watchdog Reset Setting
JP2
JP3 Reset CMOS
LVDS Voltage Setting
JP4
JP5 Compact Flash Power Setting: 5V
Serial Port2 RS-232/422/485 Setting
JP6
Serial Port2 RS-232/422/485 Setting
JP7
Serial Port2 RS-232/422/485 Setting
JP8
8
Default Setting
Jumpers and Connectors
Jumper Setting
Short 1-3, 2-4
Open
Short 1-2
Short 1-2
Short 2-3
Short 3-5
Short 4-6
Short 3-5
Short 4-6
Short 1-2
