SBC82810 Pentium
Onboard Multi I/O:
One floppy port supporting up to two devices (LS-120 &
ZIP Bootable)
One SPP/EPP/ECP parallel port; supports LS-120
Two 16550 UART-compatible serial ports
1 x RS-232
1 x RS-232/422/485 and selectable via jumper setting
and auto flow control supported
1 x IrDA for wireless communication
USB Interface: 4 USB ports with fuse protection and
Real Time Clock: Integrated Intel
Watchdog Timer:
Integrate Intel
1024 levels, 0~600 seconds with SMI and Reset feature
Hardware Monitoring:
Integrate Winbond W83627HF Super I/O.
Monitoring for CPU/System temperatures,
System Voltage and Chassis/CPU Fan speeds
Graphics/Streaming:
Integrate Intel
Unified Memory Architecture shares system memory
up to 32MB
Single display mode maximum resolutions:
CRT: 2548 x 1536
LVDS LCD: 1600 x 1200
DVI: 1280 x 1024
DualView display mode:
CRT: 2548 x 1536
LVDS LCD: 1600 x 1200
DVI: 1280 x 1024
LCD backlight control supported
Introduction
®
M All-in-One Half-Size Board User's Manual
complies with USB Spec. Rev. 2.0
®
6300ESB
®
852GM GMCH
®
6300ESB
3
