connecting an external speaker, set these jumpers to Open
and install the speaker cable on pin 8 (+) and pin 2 (-).
ATX Power On/Off Button
This 2-pin connector, designated at Pins 9 & 10 of CN4,
connects the ATX power button of the front panel to the
SBC82810 CPU card - allowing user to control the power on/off
state of the ATX power supply.
System Reset Switch
Pins 11 & 12 of CN4 connect to the case-mounted reset switch
and allow rebooting of your computer instead of turning OFF
the power switch. This is a preferred method of rebooting in
order to prolong the life of the system's power supply.
HDD Activity LED
This connector extends to the hard drive activity LED on the
control panel. This LED will flash when the HDD is being
accessed. Pins 15 & 16 of CN4 connect the hard disk drive
and the front panel HDD LED. Pins 15 is -, and pin 16 is
assigned as +.
Keyboard Lock
Pins 13 and 14 of CN4 are Keyboard Lock setting. Short the
Pins 13 and 14 for Keyboard Lock.
