SBC82810 Pentium
2.4

Connectors

The connectors allow the CPU card to connect with other parts
of the system. Some problems encountered by your system
may be a result from loose or improper connections. Ensure
that all connectors are in place and firmly attached. The
following table lists the function of each connector on the
SBC82810 Series. Their corresponding pin assignments are
described in Chapter 3.
IrDA Connector
DDR Connector
Audio Connector
Front Panel Bezel Connector
Parallel IDE Connector
Parallel Port Connector
LAN2 RJ-45 Connector
FDD Connector
Serial ATA Channel2 Connector
LAN1 RJ-45 Connector
Serial ATA Channel1 Connector
ACPI Power Connector
LVDS Channel A Connector
LVDS Channel B Connector
Serial Port1 Connector
LVDS Voltage Connecto
DVI Connector
Serial Port2 Connector
USB Port0 & Port1 Connector
Power Connector
USB Port2 & Port3 Connector
6-Pin Mini Dim Keyboard/Mouse Connector
5-Pin Mouse Connector
5-Pin Keyboard Connector
+12V Power Connector
Compact Flash Connector
Jumpers and Connectors
®
M All-in-One Half-Size Board User's Manual
Connectors
Label
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11
CN12
CN13
CN14
CN15
CN16
CN17
CN18
CN19
CN20
CN21
CN22
CN23
CN24
CN25
CN26
11
