SBC82810 Pentium

3.16 ACPI Connector

Advanced Configuration and Power Interface (ACPI) defines a
flexible and extensible interface that allows system designers
to select appropriate
management. The interface enables and supports reliable
power management through improved hardware and operating
system coordination. The specification enables new power
management technology to evolve independently in operating
systems and hardware while ensuring that they continue to
work together.
CN12 on the SBC82810 is a 6-pin header connector that
provides ACPI interface.

3.17 Pin Assignments of Other Connectors

3.17.1 CN25: Extra Power Connector Pin
Assignment
Pin Description
GND
1
3 12V
Hardware Description
®
M All-in-One Half-Size Board User's Manual
cost/feature trade-offs
CN12
1 2 3 4 5 6
G P G
E P S
N W N
X W B
D _ D
T _ 5
B
S O V
N
M N
I
Pin Description
GND
2
4 12V
for power
27
