2.6.1

CMOS Battery Power Consumption

The CMOS battery power consumption value listed above should not be used to calculate CMOS battery lifetime. You should measure the
CMOS battery power consumption in your customer specific application in worst case conditions, for example during high temperature and high
battery voltage. The self-discharge of the battery must also be considered when determining CMOS battery lifetime. For more information about
calculating CMOS battery lifetime refer to application note AN9_RTC_Battery_Lifetime.pdf on congatec AG website at www.congatec.com.
2.7

Environmental Specifications

Temperature
Humidity
Caution
The above operating temperatures must be strictly adhered to at all times. When using a heatspreader, the maximum operating temperature
refers to any measurable spot on the heatspreader's surface.
congatec AG strongly recommends that you use the appropriate congatec module heatspreader as a thermal interface between the module
and your application specific cooling solution.
If for some reason it is not possible to use the appropriate congatec module heatspreader, then it is the responsibility of the operator to ensure
that all components found on the module operate within the component manufacturer's specified temperature range.
For more information about operating a congatec module without heatspreader, contact congatec technical support.
Humidity specifications are for non-condensing conditions.
Copyright © 2013 congatec AG
RTC @ 20ºC
Integrated in the Intel 8 Series PCH-LP
®
Operation: 0° to 60°C Storage: -20° to +80°C
Operation: 10% to 90% Storage: 5% to 95%
Voltage Current
3V DC 9 µA
TU87m10 18/108
