Feature
Native PCI Express Support
Native ASPM
ACPI Debug
ACPI 5.0 CPPC Support
ACPI 5.0 CPPC Platform SCI Disabled
Active Trip Point
Automatic Critical Trip Point
Critical Trip Point Value
Lid Support
Sleep Button Support
10.4.7

RTC Wake Submenu

Feature
Wake System At Fixed Time
Wake up hour
Wake up minute
Wake up second
Copyright © 2013 congatec AG
Options Description
Disabled Enable or disable native OS PCI Express support.
Enabled
Disabled Enabled = The OS will control the ASPM support of the PCI Express device.
Enabled Disabled = The BIOS will control the ASPM support of the PCI Express device.
Disabled
Open a memory buffer for storing debug strings. Use method ADBG to write strings to buffer.
Enabled
Disabled Enable ACPI 5.0 Collaborative Processor Performance Control (CPPC) support.
Enabled When enabled, platform exposes CPPC interfaces to operating system.
When disabled, platform exposes legacy (non-CPPC) processor interfaces to operating system.
Enable ACPI 5.0 platform generation of SCI on CPPC command completion.
Enabled When enabled, platform generates GPE/SCI.
When disabled platform does not generate GPE/SCI and OS polls for command completion.
Disabled, 15 C, 23 C, Specifies the temperature threshold at which the ACPI aware OS turns the fan on/off.
31 C, 39 C, 47 C,
55 C, 63 C, 71 C,
79 C, 87 C, 95 C,
103 C, 111 C, 119 C
Disabled
Enabled = Configure the critical trip point - the temperature threshold at which the ACPI aware OS performs
Enabled a critical shutdown - automatically to recommended value.
Disabled = Configure the critical trip point manually.
71 C, 79 C, 87 C, Specifies the temperature threshold at which the ACPI aware OS performs a critical shutdown.
95 C, 103 C, 106 C,
111 C, 119 C, 127 C
Disabled
Configure COM Express LID# Signal to act as ACPI lid.
Enabled
Disabled Configure COM Express SLEEP# signal to act as ACPI sleep button.
Enabled
Options Description
Disabled Enable system to wake from S5 using RTC alarm.
Enabled
Specify wake up hour. For example, enter "3" for 3am and "15" for 3pm.
Specify wake up minute.
Specify wake up second.
TU87m10 83/108
