USB Submenu

Feature
USB Devices
xHCI Mode
EHCI (Ports USB0-7)
USB2.0 Pins Routing
USB2.0 Port 0 Pins
USB2.0 Port 1 Pins
USB2.0 Port 2 Pins
USB2.0 Port 3 Pins
USB2.0 Port 4 Pins
USB2.0 Port 5 Pins
USB2.0 Port 6 Pins
USB2.0 Port 7 Pins
USB3.0 Pins
USB3.0 Port 0 Pins
Copyright © 2013 congatec AG
Options Description
no option Displays the detected USB devices.
Smart Auto Smart Auto – The BIOS will store the USB mode set by the OS and at next boot the BIOS will set this
Auto previously used mode. At G3 boot (first boot after mechanical disconnection of the power supply) the USB
Enabled ports will function identically as in Auto mode.
Disabled
Manual Auto – All USB ports are initially set to operate in USB2.0 Mode and the USB3.0 OS driver (if available) will
switch the USB3.0 capable ports to USB3.0 mode. If USB3.0 OS driver is not available then the ports will
function correctly but will operate in USB2.0 mode.
Enabled – USB2.0 and USB3.0 ports will function correctly in BIOS but will not function at all under OS if
the USB3.0 OS driver is not installed.
Disabled – All USB ports will function in USB2.0 mode only. No USB3.0 OS driver required.
Manual – Using the settings under USB2.0 Pins Routing and USB3.0 Pins, the characteristics of the USB
ports can be set individually.
Disabled Enable or disable EHCI (USB 2.0) controller. One EHCI controller must always be enabled.
Enabled
Route Per-Pin Route USB2.0 pins to EHCI or xHCI controller.
Route all Pins to EHCI
Route all Pins to xHCI
Route to EHCI Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Route to EHCI Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Route to EHCI Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Route to EHCI Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Route to EHCI Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Route to EHCI
Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Route to EHCI Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Route to EHCI Route the respective USB2.0 port to EHCI or xHCI controller.
Route to xHCI
Select Per-Pin Enable or disable xHCI SuperSpeed support.
Disable all Pins
Enable all Pins
Disabled Enable or disable the xHCI SuperSpeed support on respective USB port.
Enabled
