10.4.16

Serial Port Console Redirection Submenu

Feature
COM0
Console Redirection
►Console Redirection Settings submenu
COM1
Console Redirection
►Console Redirection Settings submenu
Note
The Serial Port Console Redirection can be enabled (functional) only if an external Super I/O offering UARTs has been implemented on the
carrier board

10.4.16.1 Console Redirection Settings Submenu

Feature
Terminal Type
Baudrate
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Copyright © 2013 congatec AG
Options Description
Disabled Enable or disable serial port 0 console redirection.
Enabled
Opens console redirection configuration sub menu.
Disabled Enable or disable serial port 1 console redirection.
Enabled
Opens console redirection configuration sub menu.
Options Description
VT100 Select terminal type.
VT100+
VT-UTF8
ANSI
9600, 19200, 38400, Select baud rate.
57600, 115200
7, Set number of data bits.
8
None Select parity.
Even
Odd
Mark
Space
1 Set number of stop bits.
2
None Select flow control.
Hardware RTS/CTS
Disabled Enable VT-UTF8 combination key support for ANSI/VT100 terminals
Enabled
Disabled
With recorder mode enabled, only text output will be sent over the terminal. This is helpful to capture and
Enabled record terminal data.
Disabled Enables or disables extended terminal resolution.
Enabled
