Feature
Digital Display Interface 2
(DDI2)
►GOP Configuration
10.4.1.1

GOP Configuration Submenu

Feature
Output Device
BIST Enable
10.4.2

Watchdog Submenu

Feature Options
Disabled
POST Watchdog
30sec
1min
2min
5min
10min
30min
Stop Watchdog for No
Yes
User Interaction
Runtime Watchdog Disabled
One-time Trigger
Single Event
Repeated Event
Delay Disabled
10sec
30sec
1min
2min
5min
10min
30min
Copyright © 2013 congatec AG
Options Description
Auto Selection Select the output type of the digital display interface.
Disabled
Display Port
HDMI/DVI
submenu Configure graphics output when using the UEFI Graphics Output Protocol (GOP) driver instead of
legacy video BIOS. Only visible if GOP driver is configured to be used in the 'Video Option ROM
Launch Policy' setup node.
Options
(options depend on detected display devices)
Disabled
Enabled
Description
Select the timeout value for the POST watchdog.
The watchdog is only active during the power-on-self-test of the system and provides a facility to prevent errors during boot
up by performing a reset.
Select whether the POST watchdog should be stopped during the popup boot selection menu or while waiting for setup
password insertion.
Selects the operating mode of the runtime watchdog. This watchdog will be initialized just before the operating system starts
booting.
If set to 'One-time Trigger' the watchdog will be disabled after the first trigger.
If set to 'Single Event', every stage will be executed only once, then the watchdog will be disabled.
If set to 'Repeated Event' the last stage will be executed repeatedly until a reset occurs.
Select the delay time before the runtime watchdog becomes active. This ensures that an operating system has enough time
to load.
Description
Select boot display device in GOP driver mode.
Starts or stops the BIST (built in self test) on the integrated display panel.
TU87m10 76/108
