Feature Options
Event 1 ACPI Event
Reset
Power Button
Event 2 Disabled
ACPI Event
Reset
Power Button
Event 3 Disabled
ACPI Event
Reset
Power Button
Timeout 1 1sec
2sec
5sec
10sec
30sec
1min
2min
5min
10min
30min
Timeout 2 see above
Timeout 3 see above
Shutdown
Watchdog ACPI
Event Restart
Note
In ACPI mode, it is not possible for a "Watchdog ACPI Event" handler to directly restart or shutdown the OS. For this reason the congatec BIOS
will do one of the following:
For Shutdown: An over temperature notification is executed. This causes the OS to shut down in an orderly fashion.
For Restart: An ACPI fatal error is reported to the OS.
Additionally, the conga-TC87 module does not support the watchdog NMI mode. COM Express type 6 modules do not support the PCI bus
and therefore the PCI_SERR# signal is not available. There is no way to drive a NMI to the processor without the presence of the PCI_SERR#
PCI bus signal.
Copyright © 2013 congatec AG
Description
Selects the type of event that will be generated when timeout 1 is reached. For more information about ACPI Event, see note
below.
Selects the type of event that will be generated when timeout 2 is reached.
Selects the type of event that will be generated when timeout 3 is reached.
Selects the timeout value for the first stage watchdog event.
Selects the timeout value for the second stage watchdog event.
Selects the timeout value for the third stage watchdog event.
Select the operating system event that is initiated by the watchdog ACPI event. These options perform a critical but orderly
operating system shutdown or restart.
TU87m10 77/108
