Introduction

This guide contains information about the Extron
Receiver with instructions for experienced installers on how to install, configure, and operate
the equipment.
In this guide the following terms are applicable:
•
•

MTP/HDMI U R Description

The Extron MTP/HDMI Universal Receiver is used for long-distance distribution of digital and
analog RGB, component (bi-/tri- level), S-video, or composite video signals over twisted pair
cables. The receivers auto detect video formats and RS-232/audio signals, enabling the signal
to be output on the appropriate rear panel connector.
The MTP/HDMI U R is part of the Extron line of twisted pair transmitters, receivers, and
associated video accessories.
The MTP/HDMI U R receives digital or analog signals on RJ-45 connectors over
Extron A/V UTP cable, Category (CAT) 5/5e/6 or Extron DTP26 shielded twisted pair (STP),
unshielded twisted pair (UTP), or foil shielded twisted pair (FTP) cable.
They are compatible with these Extron devices:
•
•
The receiver outputs the RGBHV and RGBS video on the 15-pin HD connector, Y, R-Y, and
B-Y signals. Composite video is output on BNC connectors. S-video is output on the 4-pin
mini DIN connector. Digital output is made on the HDMI connector.
NOTE:
RS-232 (serial) communications are passed on 3-pole captive screw connectors, and audio
signals on a 5-pole captive screw connector.
The receiver is able to receive RS-232 commands from the transmitter and pass RS-232
responses back to the transmitter. RS-232 via the digital output is always bidirectional, and
the analog RS-232 can be set to either bidirectional or unidirectional, depending on the
internal jumper settings.
NOTE:
"Transmitter" refers primarily to an MTP transmitter, but could also include an
HDMI 201 Tx transmitter.
"Receiver" refers to the MTP/HDMI U R receiver.
All MTP transmitters, DAs, and switchers
DVI 201 and HDMI 201 transmitters
The analog video auto detection feature is sensitive to video signals with high
levels and/or over-peaked signals, which may result in video detection issues.
Hardware flow control is not supported.
® MTP/HDMI U R Twisted Pair Universal
MTP/HDMI U R • Introduction 1
