Extron electronics MTP T 15HD RS User Manual

Extron electronics MTP T 15HD RS User Manual

Mtp 15hd rs series high resolution video and serial link mtp transmitters and receivers
Hide thumbs Also See for MTP T 15HD RS:

Advertisement

Quick Links

User Guide
Twisted Pair
MTP 15HD RS Series
High Resolution Video and Serial Link
MTP Transmitters and Receivers
68-925-02 Rev. F
08 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTP T 15HD RS and is the answer not in the manual?

Questions and answers

Summary of Contents for Extron electronics MTP T 15HD RS

  • Page 1 User Guide Twisted Pair MTP 15HD RS Series High Resolution Video and Serial Link MTP Transmitters and Receivers 68-925-02 Rev. F 08 11...
  • Page 2 Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source indicated on the product. This This symbol is intended to alert the user of important operating and maintenance equipment is intended to be used with a main power system with a grounded (neutral) conductor. The (servicing) instructions in the literature provided with the equipment.
  • Page 3 CAUTION: A caution warns of things or actions that might damage the equipment. WARNING: A warning warns of things or actions that might cause injury, death, or other severe consequences. Copyright © 2011 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners.
  • Page 4: Table Of Contents

    Contents Introduction ..........About this Guide ..........1 About the MTP Transmitters and Receivers ..2 Twisted Pair Cable Advantages ..... 3 Transmission Distance ........3 Receiver Jumpering .......... 5 Installation and Operation ..... Installation and Operation Overview ....6 Front Panel Features .........
  • Page 5: Introduction

    CAT 5, 5e, and 6 shielded twisted pair (STP), unshielded twisted pair (UTP), or foil shielded twisted pair (FTP) cable. MTP C7 (CAT 7, C7) products that are compatible with Extron STP201 or CAT 7 cable only. In this guide, any reference to these products refers to either family, unless explicitly stated.
  • Page 6: About The Mtp Transmitters And Receivers

    About the MTP Transmitters and Receivers The Extron MTP T 15HD RS transmitter and MTP RL 15HD RS and MTP RL 15HD RS SEQ receivers are a system for long-distance distribution of VGA or other high resolution video and RS-232 serial communications.
  • Page 7: Twisted Pair Cable Advantages

    4 specifies the recommended maximum item transmission distances and transmitter Pre-Peak switch positions (see on page 10) using Extron Enhanced Skew-Free A/V UTP cable, STP201 cable, or CAT 5, 5e, 6, or 7 cable, terminated with RJ-45 connectors. NOTES: •...
  • Page 8 Video Pre-Peak Pre-Peak Max. distance Max. distance Format (high quality) (variable quality) Composite, 800' 1000' S-video, (245 m) (300 m) Component <300' >350' 700' 750' 640x480 (90 m) (105 m) (215 m) (240 m) <300' >350' 550' 650' 800x600 (90 m) (105 m) (165 m) (200 m)
  • Page 9: Receiver Jumpering

    Receiver Jumpering By default, the receiver is unidirectional, configured to send serial data from the transmitter to the receiver, only. If the system has only one receiver, this jumper can be repositioned to enable bidirectional communication as follows: If applicable, disconnect all cables, remove the receiver from its installation location, and remove any mounting brackets installed.
  • Page 10: Installation And Operation

    Twisted Pair Cable Termination Skew Delay Compensation Installation and Operation Overview Follow the steps below to properly install and operate any of the Extron MTP 15HD RS transmitters and receivers. CAUTION: Do not connect these devices to a computer data or telecommunications network.
  • Page 11: Front Panel Features

    Front Panel Features See figure 3 below to identify the front panel features on the transmitter and receiver. MTP SERIES MTP T 15HD RS transmitter LEVEL PEAKING MTP SERIES MTP RL 15HD RS receiver DELAY LEVEL PEAKING SELECT GREEN BLUE...
  • Page 12 Select button (SEQ model only) — This recessed button selects the Red, Green, or Blue video signal to adjust and resets all three video signals to a skew delay of zero nanoseconds. Use a small screwdriver to press and release this button to cycle among selecting the Red, Green, or Blue video signal to adjust.
  • Page 13: Transmitter Rear Panel Features

    Transmitter Rear Panel Features Figure 4 shows an MTP T 15HD RS transmitter, which has all of the connectors and other features that are on either transmitter in the MTP 15HD RS series. NOTE: A “C7” label is affixed to...
  • Page 14 RS-232 connector — Connect a serial communications port to this 3.5 mm, 3-pole captive screw connector for bidirectional RS-232 communication. Wire the connector as shown in figure 6. Connected RS-232 Device Pins Pins Receive Transmit Ground Figure 6. RS-232 Connector Wiring NOTES: •...
  • Page 15: Receiver Rear Panel Features

    Receiver Rear Panel Features Figure 7 shows an MTP RL 15HD RS receiver, which has all of the connectors and other features that are on either receiver in the MTP 15HD RS series. NOTE A “C7” label is affixed to NOTE: A “C7”...
  • Page 16 DIP switches (RL receivers only) — A 6-pole DIP switch is used to configure the features of the MTP receivers. Horizontal sync (H Sync +) switch — Set this switch On (up) for positive horizontal sync or Off (down) for negative sync. Vertical sync (V Sync +) switch —...
  • Page 17: Power Supply Wiring

    Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling spaces or in wall cavities. The power supply is to be located within the same vicinity as the Extron A/V processing equipment in an ordinary location, Pollution Degree 2, secured to the equipment rack within the dedicated closet, podium, or desk.
  • Page 18: Twisted Pair Cable Termination

    Use the supplied tie-wrap to strap the power cord to the extended tail of the connector. As an alternative, an Extron PS 124 Universal 12 VDC Power Supply (part number 60-1022-01) can power multiple MTPs or other Extron 12 VDC devices using only one AC power connector.
  • Page 19: Skew Delay Compensation

    Non-SEQ Receiver Skew Compensation Try using the following methods to minimize or eliminate pair skew: Switch to Extron Enhanced Skew-Free A/V UTP cable. Add a skew compensation cable equal to the length of pair skew to the output of the receiver.
  • Page 20: Reference Information

    Gain ..........Unity Number/signal type ....... 1 set of proprietary analog signals Connectors ........1 female RJ-45 Video input and loop-through — transmitter (MTP T 15HD RS) Number/signal type ....... 1 analog RGBHV, RGBS, RGsB, RsGsBs, component video, S-video, or composite video 1 buffered RGBHV, RGBS, RGsB, RsGsBs local monitor loop through (includes ID bits) Connectors ........
  • Page 21 Control/remote — external device (pass-through, unidirectional or bidirectional) Serial control port input/output MTP C7 T 15HD RS, MTP T 15HD RS RS-232 via (1) 3.5 mm, 3 pole captive screw connector Receivers ........1 set of proprietary signals on a female RJ-45 jack...
  • Page 22: Part Numbers, Optional Accessories, Cables, And Connectors

    Specifications are subject to change without notice. Part Numbers, Optional Accessories, Cables, and Connectors Part Numbers MTP Transmitter and Receivers for non-CAT 7 Cable Part Number MTP T 15HD RS transmitter 60-652-01 or MTP RL 15HD RS receiver 60-735-01 or MTP RL 15HD RS SEQ receiver...
  • Page 23: Optional Accessories

    RSU 129 (9.5 inches deep, 1U rack shelf kit) 60-190-01 RSB 129 (9.5 inches deep, 1U basic rack shelf) 60-604-02 Cables NOTE: Extron Enhanced Skew-Free A/V UTP cables are not recommended for Ethernet or LAN applications. Description Part Number VGA connector cable 26-238-xx...
  • Page 24: Mounting

    Under-desk and Furniture Mounting Mount the unit under a desk or podium using the optional Extron MBU 123 under desk mounting kit (part number 70-212-01). To mount the unit, follow the instructions provided with the MBU 123 kit.
  • Page 25: Rack Mounting Procedure

    Back of the Rack Mounting Procedure The MTP can be mounted to the rear of a rack using the Extron MBB 100 1/8 and 1/4 back of rack mounting kit (part number 70-367-01). The kit allows the product to be vertically mounted to the front or rear rack supports and facing either towards the front or the rear of the rack.
  • Page 26 Extron. NOTE: If a product is defective, please call Extron and ask for an Application Engineer to receive an RA (Return Authorization) number. This will begin the repair process.
