Control/remote — external device (pass-through) from the HDMI input
Serial control port input/output ...... RS-232 via (1) 3.5 mm, 3 pole captive screw connector
Baud rates ...................................... Up to 38400 bps at up to 600' (183 m) (Higher data rates and distances are possible.
NOTE: Protocol is mirrored between the transmitter and the receiver.
Serial control pin configuration ....... Captive screw connector: 1 = Tx, 2 = Rx, 3 = GND
Control/remote — external device (pass-through, unidirectional or
bidirectional) from the MTP input
Serial control port input/output ...... RS-232 via (1) 3.5 mm, 5 pole captive screw connector (3 poles are used)
Baud rates ...................................... Up to 38400 bps at up to 600' (183 m) (Higher data rates and distances are possible.
NOTE: Protocol is mirrored between the transmitter and the receiver.
Serial control pin configuration ....... Captive screw connector: 1 = Tx, 2 = Rx, 3 = GND
General
Recommended cable type .............. Shielded or unshielded
MTP input ................................ CAT 5/5e/6
HDMI digital input ................... CAT 5/5e/6, Extron DTP26
External power supply .................... 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements .............. 12 VDC, 0.8 A
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, no vents
Thermal dissipation
115 VAC, 60 Hz ....................... 16.7 BTU/hr
240 VAC, 50 Hz ....................... 18.1 BTU/hr
Mounting
Rack mount ............................. Yes, with optional 1U rack shelf
Furniture mount ...................... Yes, with optional under-desk mounting kit
Pole mount .............................. Yes, with optional projector mounting kit
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.7" H x 8.75" W x 3.0" D (half rack wide)
Product weight ............................... 0.8 lbs (0.4 kg)
Shipping weight ............................. 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.
Performance varies based on baud rate and cable length.)
Performance varies based on baud rate and cable length.)
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(4.3 cm H x 22.2 cm W x 7.6 cm D)
(Depth excludes connectors.)
UL rated for use in plenum airspaces: meets UL 2043 for heat and smoke release,
excluding the power supply.
