- Page 1 User Guide Twisted Pair MTP 15HD A Series High Resolution Video and Serial Link MTP Transmitters and Receivers 68-2206-01 Rev. B 03 13...
-
Page 2: Safety Instructions
Safety Instructions Safety Instructions • English Chinese Simplified （简体中文） 警告： 产品上的这个标志意在警告用户该产品机壳内有暴露的危险 WARNING: This symbol, , when used on the product, is intended to alert the user of the presence of uninsulated dangerous voltage within 电压， 有触电危险。 the product’s enclosure that may present a risk of electric shock. 注... - Page 3 Extron Safety and Regulatory ” on the Extron website Compliance Guide Copyright © 2013 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks , registered service marks...
- Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: A warning indicates a situation that has the potential to result in death or WARNING: severe injury. ATTENTION: Attention indicates a situation that may damage or destroy the product or associated equipment.
-
Page 5: Table Of Contents
Using a Pre-Programmed or User-Recorded EDID ........ 16 Reference Information ......Part Numbers, Optional Accessories, Cables, and Connectors ....... 17 Part Numbers ..........17 Optional Accessories ......... 17 Cables ............18 Connectors ..........18 MTP 15HD A Series • Contents... -
Page 6: Introduction
Introduction This section gives an overview of the user guide. This section also describes the MTP 15HD A Series of transmitters and receivers. Covered topics are: • About this Guide • About the MTP Transmitters and Receivers • Transmission Distance... -
Page 7: About The Mtp Transmitters And Receivers
100 VAC to 240 VAC, 50-60 Hz input. Twisted Pair Cable Advantages Twisted pair cable is smaller, lighter, more flexible, and less expensive than coaxial cable. Termination of the cable with RJ-45 connectors is simple, quick, and economical. MTP 15HD A Series • Introduction... -
Page 8: Transmission Distance
100 feet (30 m) from the transmitter when the Pre-Peak switch is on. • For daisy-chained units, any receiver in the chain closer than 350 feet (105 m) may experience some form of over-peaking when the Pre-Peak switch is on. An over-peaked image may appear bloomed. MTP 15HD A Series • Introduction... - Page 9 • Resolutions marked with an asterisk (*) in the table above have the same range specifications at 75 Hz. • It is possible to exceed the recommended distance; however, image quality may be reduced. MTP 15HD A Series • Introduction...
-
Page 10: Installation And Operation
Adjust the level and peaking (see Front Panel Features on page 6). Front Panel Features Adjust the skew delay control (see on page 6). If applicable, mount the MTPs (see Mounting on page 19). MTP 15HD A Series • Installation and Operation... -
Page 11: Front Panel Features
NOTE: When the EDID select rotary switch ( ) is in position 0 or F, the setting of the first DIP switch is not applicable because the user-recorded or attached display EDID is being used. MTP 15HD A Series • Installation and Operation... - Page 12 Watch the displayed image to observe the steps of delay. • The selected Red, Green, or Blue LED ( ) flashes to indicate that the control has reached the minimum (counterclockwise rotation) or maximum (clockwise rotation) limit. MTP 15HD A Series • Installation and Operation...
- Page 13 The receiver being configured is the last receiver in a daisy-chained system. • • Set the End Unit switch Off (down) on the receiver being configured if there are one or more receivers connected to the Buffered Output RJ-45 connector (see figure 6, MTP 15HD A Series • Installation and Operation...
-
Page 14: Transmitter Rear Panel Features
Transmitter Rear Panel Features Figure 3 shows an MTP T 15HD A transmitter, which has all of the connectors and other features that are on either transmitter in the MTP 15HD A series. MTP T 15HD A Transmitter NOTE: A “C7” label is affixed to... - Page 15 RJ-45 female connector on the receiver (see Twisted Pair Cable Termination page 14 to wire the RJ-45 connectors). ATTENTION: Potential damage to property. Do not connect these devices to a computer data or telecommunications network. MTP 15HD A Series • Installation and Operation...
-
Page 16: Receiver Rear Panel Features
Receiver Rear Panel Features Figure 6 shows an MTP RL 15HD A receiver, which has all of the connectors and other features that are on either receiver in the MTP 15HD A series. NOTE: A “C7” label is affixed to... -
Page 17: Power Supply Wiring And Grounding
• Do not tin the power supply leads before installing in the direct insertion connector. Tinned wires are not as secure in the connectors and could be pulled out of the connector. MTP 15HD A Series • Installation and Operation... - Page 18 As an alternative, an Extron PS 124 Universal 12 VDC Power Supply (part number 60-1022-01) can power multiple MTPs or other Extron 12 VDC devices using only one AC power connector. MTP 15HD A Series • Installation and Operation...
-
Page 19: Twisted Pair Cable Termination
The green, brown, and blue wire pairs of this cable have virtually identical lengths and should be used to transmit the RGB signals. • The orange wire pair of this cable has a different length and should not be used to transmit the RGB signals. MTP 15HD A Series • Installation and Operation... -
Page 20: Skew Delay Compensation
Add a skew compensation cable equal to the length of pair skew to the output of the receiver. • Install an SEQ 100 15HD Skew Equalizer to the video output of the receiver and adjust the skew for the leading video image. MTP 15HD A Series • Installation and Operation... -
Page 21: Edid Configuration
Position F passes the EDID from the display connected to the loop-out directly back to the input. Rotary Switch Resolution Position User-recorded EDID 800x600 1024x768 (default) 1280x720 1280x768 1280x800 1280x1024 1360x768 1366x768 1400x1050 1400x900 1600x1200 1680x1050 1920x1080 1920x1200 Local monitor pass-through MTP 15HD A Series • Installation and Operation... -
Page 22: Reference Information
IEC power cord 27-044-01 5-pole captive screw connector 10-703-12LF (4) Rubber feet (not attached) Tweeker Setup Guide — MTP 15HD A Series Optional Accessories Description Part Number PS 124 multiple output 12 volt DC power supply 60-1022-01 MBB 100 (1/8 and 1/4 back of rack mounting kit) -
Page 23: Cables
CAT 6 jack (Orange), quantity 10 100-479-01 CAT 6 jack (Gray), quantity 10 100-480-01 CAT 6 jack (White), quantity 10 100-481-01 CAT 6 jack (Ivory), quantity 10 100-482-01 Shielded RJ-45 for STP201 cable 101-005-01 MTP 15HD A Series • Reference Information... -
Page 24: Mounting
Mounting This section outlines the various mounting options available for the MTP 15HD A Series transmitters and receivers: • Tabletop Placement • Under-Desk Mounting • Rack Mounting • Projector Mounting Tabletop Placement Attach the four provided rubber feet to the bottom of the unit and place it in any convenient location. -
Page 25: Rack Mounting Procedure
Mount the unit onto a projector using the optional Extron PMK 100 1/4 rack width pole mount kit (part number 70-217-01). To mount the unit, follow the instructions provided with the PMK 100 kit. MTP 15HD A Series • Mounting... - Page 26 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
